Amana AOES3030 Technical Information

Amana Electric Wall OvenTechnical Information
AOES3030 P1132347N, P1132354N, P1132374N, P1132379N
AOCS3040 P1132348N, P1132353N, P1132372N, P1132375N, P1132378N
• Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this unit.
• Refer to Service Manual 16021875 for detailed installation, operating, testing, troubleshooting, and disassembly
instructions.
• This technical sheet replaces RT2520001 Rev. 2.
All safety information must be followed as provided in Service Manual 16021875.
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires it.
Models
Power Source
Electrical rating
Amperage
Frequency
Oven Wattage @ 240 V
Convection
Bake
Broil
Oven Interior Dimensions in. (cm)
Height
Width
Depth
Product Exterior Dimensions in. (cm)
Height
Width of trim frame
Depth oven door closed with handle
Clearance oven door
Weight lbs. (kg)
Approximately shipping weight
Unit Features
®
Touchmatic electronic oven control
Pivotal control panel
Exclusive Insta-Broil broiling system
Concealed bake element
Spillsaver oven bottom
Removable counterbalanced glass oven door
with extra-large viewing window
Interior oven light
Automatic oven door latch
Porcelain broiler pan and grid
Heavy duty oven racks with six positions
Slo-Cook Rack
Convection broiling rack
Multi-Mode convection cooking system
November 2003
©2003 Maytag Appliances Company
!
CAUTION
!
WARNING
AOES3030
240 VAC 120/208 VAC
5.2 kW 3.95 KW
30 Amp max.
60 Hz
2,000 / 1733
3,000 / 2253
16 (41)
23 (58)
18 (45.6)
27 1/4 (69)
29 3/4 (72)
26 1/2 (67)
20 (50.8)
160 (72.5)
X
X
X
X
X
X
X
X
X
Two racks
—
—
—
1
AOCS3040
240 VAC 120/208 VAC
5.2 kW 3.95 KW
30 Amp max.
60 Hz
2,200 / 1650
2,000 / 1733
3,000 / 2253
16 (41)
23 (58)
16 1/2 (41.9)
27 1/4 (69)
29 3/4 (72)
26 1/2 (67)
20 (50.8)
170 (77.1)
X
X
X
X
X
X
X
X
X
Four racks
X
X
X
16021876
