INSTALLATION
INSTRUCTIONS
27² ² ² ² SINGLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 142 lbs.)
DIMENSIONS
inches
A
27 MIN
B
24 MIN
C
27 7/8 + 1/16
D
24.0
E
25 1/2 + 1/16
F
28 1/4
G
26 3/4
H
24 7/16
I
4 to 33
27² ² ² ² DOUBLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 250 lbs.)
DIMENSIONS
inches
A
27 MIN
B
24 MIN
C
50.0 + 1/16
D
24.0
E
25 1/2 + 1/16
F
50 1/14
G
26 3/4
H
24 7/16
I
4 to 12
* * COOKTOPS
K
Electric
K
Induction
K
4 Burner Gas Stamped Top
K
4 Burner Gas Glass Top
*
NOTE:
Hole must be cut as close to corner of cabinet as possible.
**
See dealer for approved cooktops.
Built-In 27² ² ² ² & 30² ² ² ²
Electric Wall Ovens
30² ² ² ² SINGLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 142 lbs.)
cm
inches
68.58
A
30 MIN
60.96
B
24 MIN
70.80
C
27 7/8 + 1/16
60.96
D
64.77
E
28 1/2 + 1/16
71.76
F
28 1/4
67.95
G
29 3/4
62.07
H
24 7/16
10.2 to 83.8
I
4 to 33
30² ² ² ² DOUBLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 250 lbs.)
cm
inches
68.58
A
30 MIN
60.96
B
24 MIN
127.0
C
50.0 + 1/16
60.96
D
64.77
E
28 1/2 + 1/16
127.64
F
50 1/4
67.95
G
29 3/4
62.07
H
24 7/16
10.2 to 30.5
I
4 to 12
30² ² ² ² WALL OVEN UNDER COUNTER
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 142 lbs.)
inches
A
B
24 MIN
C
27 7/8 + 1/16
D
E
28 1/2
F
28 1/4
G
29 3/4
H
24 7/16
I
J
30² ² ² ² WALL OVEN
inches
cm
3 1/8 MIN
7.9 MIN
3 1/8 MIN
7.9 MIN
4 13/16 MIN
12.2 MIN
4 13/16 MIN
12.2 MIN
DIMENSIONS
cm
76.20
60.96
70.80
24.0
60.96
72.39
71.76
75.57
62.07
10.2 to 83.8
DIMENSIONS
cm
76.20
60.96
127.0
24.0
60.96
72.39
127.64
75.57
62.07
10.2 to 30.5
DIMENSIONS
cm
25
63.50
60.96
70.80
24.0
60.96
72.39
71.76
75.57
62.07
36
91.44
1 1/2
3.81
Z
Do not block air intake slots along bottom of oven.
Y
Gas or electric cooktops may be installed over ovens.
See cooktop installation instructions for cutout size.
W Electrical connection for electric cooktop must be in adjacent
accessible location. Cooktop and wall oven must be on separate
120/240 or 120/208 volt 60 Hz AC circuits.
403 WEST FOURTH STREET, NORTH
NEWTON, IA 50208
SINGLE WALL OVEN
DOUBLE WALL OVEN
UNDER COUNTER WALL OVEN
NOTES
8101P603-60
(09-03-00)
