Figure 14. 6500 Series Menu Tree - ADTRAN 6540 Installation And Maintenance Manual

SHDSL 2-Wire/4-Wire NTU Product Series Installation and Maintenance Guide
Main Menu
26
1. LTU
1. Unit Information
2. NTU
1. Unit Options
2. Provisioning
2. SHDSL Options
3. G.703 Options
4. Nx64K Options
5. Test Options
1. SHDSL Port
3. Status
2. G.703 Port
3. G.703 Services
4. Nx64K Port
5. Reset All Status
1. SHDSL Local Loopback
4. Test
2. SHDSL Remote Loopback
3. SHDSL BERT
4. G.703 Local Loopback
5. G.703 BERT
6. G.703 Services
7. Nx64k Local Loopback
8. Nx64k Remote Inband Loopback
9. Nx64k BERT
5. Performance History
1. Restart Bad Splice Detector
6. TSCAN
2. 24 Hour Counts
Local Management
7. Terminal Mode
Remote Virtual Terminal Management
* 2-wire mode: 192 kbps to 2.304 Mbps (N x 64 kbps, where N=3 to 36)
4-wire mode: 384 kbps to 4.608 Mbps (N x 64 kbps, where N=even numbers, 6 to 72)
1. Unit Mode
2. Cross-Connect Map
3. Clock Source
4. Circuit ID
5. Date and Time
6. Restore Factory Defaults
7. Upgrade Firmware
8. Local Management
9. Change Password
1. Interface Mode
2. Payload Rate (kbps) *
3. SNR Margin Alarm Threshold (dB)
4. Loop Attenuation Alarm Threshold (dB)
5. Outage Auto-Retrain
1. ES 15-Minute Alarm Threshold
6. PM Thresholds
2. SES 15-Minute Alarm Threshold
3. UAS 15-Minute Alarm Threshold
4. CVC 15-Minute Alarm Threshold
5. LOSWS 15-Minute Alarm Threshold
6. OS 15-Minute Alarm Threshold
1. ISDN-PRA V3
2. G.704 CRC-4 Multiframing
3. Timeslot Idle Pattern
4. Spare Bits Insertion to Span
5. Spare Bits Pattern to Span
6. Spare Bits Insertion
7. Spare Bits Pattern
8. RAI Generation
9. E-bit Generation
10. ES 15-Minute Alarm Threshold
11. SES 15-Minute Alarm Threshold
12. UAS 15 Minute Alarm Threshold
13. CVC 15-Minute Alarm Threshold
1. Interface Type Auto Detection
2. Interface Type Manual Select
3. Inactivity Alarm Delay (Secs)
4. Tx Clock Source
5. Tx Clock Polarity
6. X.21 C Mode
7. X.21 I Mode
8. V.35/V.36 RTS (Circuit 105)
9. V.35/V.36 RTS (Circuit 106)
10. V.35/V.36 RTS to CTS Delay (ms)
11. V.35/V.36 DSR (Circuit 107)
12. V.35/V.36 DTR (Circuit 108/2)
13. CVC 15-Minute Alarm Threshold
1. Dual Sided
1. Loopback Types
2. Transparent
3. Nontransparent
2. Inband Loopback Options
0. Disabled
3. Loopback Timeout (Min)
1-199. Time Out in Minutes
4. BERT Pattern
5. BERT Pattern Polarity
6. Pushbuttons (All)
7. SHDSL Port Select Pushbuttons
8. V.35/V.36 RL (Circuit 140)
9. V.35/V.36 LL (Circuit 141)
10. V.35/V.36 TI (Circuit 142)
1. Local Loopback
2. Remote Inband Loopback
3. BERT

Figure 14. 6500 Series Menu Tree

1. NT
2. LT
1. Internal Clock
2. Nx64 ETC(113)/X
3. G.703 Rx Clock
4. SHDSL Rx Clock
1. Disabled
2. Enabled
1. 2-Wire
2. 4-Wire
0. Disabled
1-15. Alarm Threshold
0. Disabled
1-127. Alarm Threshold
1. Disabled
2. Enabled
0. Disabled
1-900. Seconds
0. Disabled
1-65535. Seconds
0. Disabled
1-900. Seconds
1. Disabled
2. Enabled
00h to FFh
1. Disabled
2. Enabled
00h to FFh
1. Disabled
2. Enabled
00h to FFh
1. Disabled
2. Enabled
0. Disabled
1-900. Seconds
0. Disabled
1-65535. Seconds
1. Disabled
2. Enabled
1. X.21
2. V.35
3. V.36
0. Disabled
1-100. Alarm Threshold
1. From DCE, TC (Circuit 114)
2. From DTE, ETC (Circuit 113)
1. Normal
2. Inverted
3. Auto
1. Permanent On
2. DTE Driven
1. Permanent On
2. Sync Mode
1. Permanent On
2. DTE Driven
1. Permanent Off
2. Permanent On
3. RTS Driven
0 to 255 = Delay in ms
1. Permanent Off
2. Permanent On
1. Permanent On
2. DTE Driven
1. Permanent Off
2. Permanent On
3. Sync Mode
1. In-band Loopback Protocol
2. G.703 Services In-band Pattern Detection
3. Nx64k In-band Pattern Detection
1. ALT
2. 2047
3. 2E15-1
1. Normal
4. QRSS
2. Inverted
1. Disabled
2. Enabled
1. Permanent Off
2. DTE Driven
1. Permanent Off
2. Test Driven
1. Dual Sided
2. Customer Transparent
3. Customer Non-Transparent
4. Network Transparent
5. Network Non-Transparent
1. SHDSL Port
2. G.703 Port
3. Reset All
61230001E1-5E
1. PN127
2. V.54
1. Disabled
2. Enabled
1. Disabled
2. Enabled
