Transmitter Clamp
An optional signal clamp can be placed around an insulated live wire or pipe up to
8.5" / 215mm in diameter to transfer the transmitter signal to the utility. This method of
applying the transmitter signal is particularly useful on insulated live wires and removes
the need to disconnect the supply to the cable.
WARNING! Do not clamp around uninsulated live conductors.
WARNING! Before applying or removing the clamp around a power cable ensure
that the clamp is connected to the transmitter at all times.
Locating with Passive Frequencies
Passive frequency detection takes advantage of signals that are already present on buried
metallic conductors. The RD8200 supports four types of passive frequencies: Power,
Radio, CPS and Cable TV (CATV) signals. You can detect these frequencies without the
aid of the transmitter.
Power Filters
RD8200 locators allows operators to take advantage of the harmonic signals
found on power networks. Once in Power Mode, press the
Radiodetection's sensitive Power Mode and scroll through five individual Power Filters.
This enables operators to establish if a single large power signal comes from one source
or from the presence of multiple cables. The different harmonic characteristics of the
detected lines can then be used to trace and mark their route.
Additionally the use of an individual harmonic can allow you to locate power lines in
situations where the total signal would otherwise be too large.
Locate Modes
The RD8200 offers a choice of 5 locate modes, each of which is designed for specific
uses, depending on what task is being carried out.
To scroll between locate modes, press the
PEAK: For accurate locating, the peak bargraph provides a visual readout of the
signal strength. The peak signal is found directly over the buried utility.
PEAK+: Choose to combine the accuracy of the Peak bargraph with Null arrows,
which can indicate the presence of distortion, or with proportional Guidance
arrows for rapid line tracing – switch between them by holding the
GUIDANCE: Proportional arrows and a ballistic 'needle' combine with audio left/
right indication for rapidly tracing the general path of a buried utility.
BROAD PEAK: Operating similarly to Peak mode, but giving a result over a wider
area. Used to detect and trace very weak signals, for example very deep utilities.
NULL: Provides a quick left/right indication of the path of a utility. As Null is
susceptible to interference, it is best used in areas where no other utilities are present.
key to switch out of
key.
key.
16
Depth, current and compass readouts
WARNING! Never use the depth measurement readout as a guide for
mechanical or other digging activity. Always follow safe digging guidelines.
The RD8200 locator can measure and display the utility depth, locate signal current and
the relative orientation of the cable or pipe to the locator. This helps you to make sure that
you are following the right cable or pipe, especially when other utilities are present.
The RD8200 locator features TruDepth , a feature that helps you to ensure the accuracy
™
of your locates or Survey Measurements. The depth and current are automatically
removed from the display when the locator is at an angle of more than 7.5° from the path
of the cable or pipe being located, or when the locator determines that signal conditions
are too poor for reliable measurements.
Current Direction (CD)
The Tx-10 transmitter range can apply a unique CD signal onto a pipe or cable. This
signal can be used to identify an individual pipe or cable amongst a number of parallel
utilities, ensuring operators follow the right line. A CD signal clamp or direct connection
leads can be used to apply the unique signal to the pipe or cable and a CD locator clamp
or CD stethoscope can be used to identify individual pipes or cables.

Using accessories

The locator and transmitter are compatible with a wide range of accessories. For detailed
information on using any of the accessories below please refer to the RD8200 locator
operation manual.
Transmitter signal clamps
When it is not possible to connect directly onto a pipe or cable, or induction mode is
unsuitable, a transmitter signal clamp may be used. The clamp is plugged into the output
of the transmitter and provides a means of applying a locate signal to an insulated live wire.
This is particularly useful with live insulated cables as it removes the need to disable the
power and break the line.
WARNING! Do not clamp around uninsulated live conductors.
WARNING! Before applying or removing the clamp around a power cable
ensure that the clamp is connected to the transmitter at all times.
To locate or identify individual lines a locator signal clamp can be connected to the
accessory socket of the locator and can be clamped around individual pipes or cables.
