Stethoscopes and locator signal clamps
Locator clamps can be used to identify a target cable or pipe amongst a number of
different cables by checking for the strongest locate signal. When cables are bunched or
tightly packed, a stethoscope antenna can be used in place of a clamp.
To use a stethoscope or locator signal clamp, connect it to the locator's accessory socket.
The locator will automatically detect the device and filter out location modes that are
irrelevant.
Sondes, Flexrods and FlexiTrace
Sondes are battery powered transmitters that are useful for tracing non-metallic pipes.
They can be fixed to Flexrods to allow them to be pushed through pipes or conduits, and
some are suitable for blowing through ductwork.
For a detailed guide on locating sondes, please refer to the operation manual.
A FlexiTrace is a traceable fiberglass rod incorporating wire conductors with a sonde at the
end. It is connected to the output of the transmitter and is typically used in small diameter,
non-metallic pipes. The user has the option of locating the entire length of the cable or
choosing to locate only the tip of the cable.
The FlexiTrace has a maximum power rating of 1W. When using the FlexiTrace with a
Radiodetection Tx-5(B) or Tx-10(B) transmitter the output limit must be set to 1W in the
MAX P menu and the output voltage limit set to LOW in the MAX V menu.
Fault-finding with an A-Frame
The RD8200 models has the ability to detect cable or pipe insulation faults accurately
using an A-Frame accessory. The Tx-5 and Tx-10 models provide fault finding signals
that can be detected by the A-Frame as a result of the signal bleeding to ground through
damaged cable sheaths.
The Transmitter's multimeter function can be used to measure the impedance of the
connected pipe or cable in order to characterize the fault.
For a detailed guide to fault-finding, please refer to the operation manual.
Plug / Live cable connector
The plug connector is connected to the output of the transmitter and is used to put a
signal onto a line and trace it from a domestic mains plug to the service cable in the street.
The live cable connector can be used to apply a signal to a live cable. Only suitably
qualified personnel should use this equipment.

Submersible antenna

This antenna is connected to the locator and used to locate pipes and cables underwater
at depths of up to 300 feet / 100 meters.
WARNING: use of the submersible antenna should be by fully licensed and
experienced personnel only, and only after fully reading the operation manual!
18

Bluetooth wireless connections

RD8200 locators feature a Bluetooth wireless module, as standard, providing the ability
to connect to compatible devices such as transmitters (Bluetooth models), PCs, laptops
or handheld devices running a compatible application.
NOTE: The RD8200 locator wireless features may be subject to national and or
local regulations. Please consult your local authorities for more information.
WARNING! Do not attempt any wireless connection in areas where such
technology is considered hazardous. This may include: petrochemical facilities,
medical facilities or around navigation equipment.
Switching iLOC on
By default RD8200 locators and Bluetooth enabled transmitters are shipped with the
iLOC wireless connection module disabled.
1. Press the key to enter the menu.
2. Scroll to the iLOC menu using the
3. Press the key (locator) or the key (transmitter) to enter the iLOC menu.
4. Press the or keys to select the ON option.
5. Press the key to confirm selection and return to the previous menu.
6. A further press of the key will return to the main operating screen.
You can switch Bluetooth off to conserve battery life, or to comply with regulations in
areas where wireless communications are considered hazardous. To do this, follow the
above process, selecting 'OFF' in the iLOC menu.
Bluetooth error codes
If an error occurs when attempting to perform any Bluetooth command using the locator
to the transmitter or the locator to a PC or paired device, the LCD will display a code to
help you resolve the problem on the locator.
The codes are as follows:
B T C O D E D E S C R I P TI O N
BT001 Bluetooth not configured for this unit
BT002 Internal Bluetooth error
BT003 Locator not paired with transmitter
BT004 Locator not paired with PC / external compatible device
BT005 Paired but connection attempt failed. Power cycling may be required
BT006 Corrupt response received from transmitter
BT007 Indeterminate response received from transmitter
BT008 No response received from transmitter
TX?? Transmitter unable to change to the requested frequency
or keys.
