7.4 CN6 STDC14 connector
Terminal
1 -
3 VDD
5 GND
7 GND
9 -
11 GND
13 VCP_RX_STDC (PA3)
7.5 CN7 USB OTG FS Micro-AB connector
A USB OTG Full Speed communication link is available at CN7 USB Micro-AB receptacle connector. Micro-AB
receptacle enables USB Host and USB Device features.
Pin number
1
2
UM2651 - Rev 2
Figure 9. CN6 STDC14 debugging connector (Top view)
Table 10. CN6 STDC14 debugging connector pinout
Function / MCU port
Figure 10. CN7 USB OTG FS Micro-AB connector
Table 11. CN7 USB OTG FS Micro-AB connector pinout
Description
VBUS
DM
Terminal Function / MCU port
2 -
4 SWDIO/TMS (PA13)
6 SWDCLK/TCK (PA14)
8 SWO/TDO (PB3)
10 -
12 RESET#
14 VCP_TX_STDC (PA2)
Pin number
4 ID
5 GND
