4 Conventions
Table 3 provides the conventions used for the ON and OFF settings in the present document.
Solder bridge SBx ON
Solder bridge SBx OFF
UM2651 - Rev 2
Table 3.
Convention
Jumper JPx ON
Jumper JPx OFF
Jumper JPx [1-2]
Resistor Rx ON
Resistor Rx OFF
ON/OFF convention
Definition
Jumper fitted
Jumper not fitted
Jumper fitted between Pin 1 and Pin 2
SBx connections closed by 0 Ω resistor
SBx connections left open
Resistor soldered
Resistor not soldered
