ST STM32L4P5AG User Manual page 28

Pin name
PA2
PA1
VDD
OPAMP2_VINM
PB2
PF12
VDD
PE11
PB10
PH8
VDD
PB12
PB13
UM2651 - Rev 2
UFBGA169 +
Type
ext SMPS
N1 I/O
N2 I/O
N3 S
N4 I
N5 I/O
N6 I/O
N7 S
N8 I/O
N9 I/O
N10 I/O
N11 S
N12 I/O
N13 I/O
STM32L4P5G-DK I/O assignment
Input level STM32 pinout assignment
FT_la USART2_TX
FT_la ARD_ADC12_IN6
-
TT
FT_a LCD_RTC_OUT2
FT OCTOSPIM_P2_DQS
-
FT OCTOSPIM_P1_NCS
FT_fl ARD_USART3_TX
FT_f DCMI_HSYNC/DE
-
FT STMOD_DFSDM1_DATIN1
FT_fl ARD_SPI2_SCK
UM2651
-
-
-
-
page 28/37
