INSTRUCTION GUIDE
Congratulations on your purchase of a high quality PUTCO
you need any application or technical assistance, feel free to call us at:
Monday-Friday 8:00am - 5:00pm (Central Standard Time)
Contact your PUTCO
PLEASE READ ALL INSTRUCTIONS BEFORE INSTALLATION
AND CHECK TO SEE THAT ALL PARTS ARE INCLUDED
REQUIRED TOOLS
3/16" HEX KEY
7/32" HEX KEY
10MM WRENCH
RAM 1500
1-800-247-3974
dealer for other quality accessories.
®
T30 TORX DRIVER
PHILLIPS SCREWDRIVER
CONTENT LIST
`
DESCRIPTION
Molle Front Plate
Molle Side Plates
Single-Flange Side Mounting Brackets
Double-Flange Side Mounting Brackets
M6 Torx-Head Bolt
Rubber Feet
Jam Nuts
5/16" Well Nut
3/4" Well Nut
3/8"-16 X 1.5" Allen Head Bolt
8-32 X 3/4" Philip's Head Screw
5/16"-18 X 2 3/8" Allen Head Bolt
In-Bed Washer
Nut Plate
product. Should
®
QT Y
1952XXI
1
2
2
2
4
4
32
3
3
16
2
2
16
2
2
2
Advertisement
Table of Contents
Related Manuals for PUTCO MOLLE PANELS RAM 1500
Summary of Contents for PUTCO MOLLE PANELS RAM 1500
- Page 1 INSTRUCTION GUIDE RAM 1500 Congratulations on your purchase of a high quality PUTCO product. Should ® you need any application or technical assistance, feel free to call us at: 1-800-247-3974 Monday-Friday 8:00am - 5:00pm (Central Standard Time) Contact your PUTCO dealer for other quality accessories.
- Page 2 MOLLE Panels Instruction Guide INSTALLATION INSTRUCTIONS Begin by gathering all four of the Single-Flange Side Mounting Brackets and all four of the Double-Flange Side Mounting Brackets. Single-Flange Bracket Double-Flange Bracket Loosely assemble two 5/16” Well Nuts and two Philip’s Head Screws onto each of these brackets as shown.
- Page 3 MOLLE Panels Instruction Guide Next, gather the two Front Upper Brackets. Loosely assemble one 2-3/8” long Allen head bolt, In-Bed Washer, and Nut Plate onto each of these brackets. Install the Front Upper Bracket assemblies by inserting the Nut Plate into the slot located towards the top of each bed side as shown in the pictures below.
- Page 4 MOLLE Panels Instruction Guide Light Duty Ram with All Brackets Installed Next, prepare the Molle Front Plate to be installed. Thread a jam nut onto each of the rubber feet, then loosely screw the rubber feet into the riv nuts located on the bottom flange of the front plate.
