PUTCO Boss Bar Installation Instructions

2015+ Ford F150 SuperCrew 5.5ft Box
Please read all instructions before installation and to check to see that all parts are included.
Description
Driver Bar (1784)
Passenger Bar (1785)
Mounting Bracket (2022)
M8 Hex Nut (282)
M8 Hex flange bolt (278)

Boss Bar Installation

1. Remove Boss Bars from packaging. Check to see if all parts from above table of kit contents are
included.
2. Factory running boards need to be remove prior to installation, if equipped. Supplied
brackets will mount in factory locations.

Driver Side Installation

3. Install front bracket in front location. (Figure 1)
Use 3-4 M8 Hex Nuts to mount bracket to studs
on the under body of the truck, leave loose.
Note: There may only be 3 studs on the truck to
attach each bracket.
4. Install front bracket in front location. (Figure 2)
Use 3-4 M8 Hex Nuts to mount bracket to studs
on the under body of the truck, leave loose.
Installation Instructions

KIT CONTENTS:

Tools Needed:
Qty.
- 13mm Wrench
1
- Torque Wrench
1
4
16
16
Figure 1
Boss Bar
