PUTCO LUMINIX Instructions

Fog lamp

Congratulations on your purchase of a high quality PUTCO product. Should you need any

application or technical assistance feel free to call us at: 1-800-247-3974

Monday-Friday 8:00 a.m. - 5:00 p.m. (Central Standard Time)

Please read all instructions before installation and to check to see that all parts are included.

Table 1.0

Description

4.5" Round Puck with Wiring Harness

Stainless Steel Mounting bracket with caps

10-32 X 3/8" Machine Screw

#10 Lock Washers

3/8" Stainless Steel Spacer Washer

Before Installation Verify that all contents listed in Table 1.0 are included in your kit.

LIMITED 2 YEAR WARRANTY

Putco guarantees it's Stainless Steel and Aluminum products against defects in workmanship and material for as long as you own

your vehicle. All painted products have a 90 day warranty on the painted surface. Any defects resulting from faulty material or

workmanship will be warranted by Putco and repaired or replaced at our discretion. Putco assumes no extra labor costs. Damages

caused by freight carriers, improper installation, misuse, collision, or neglect will not be warranted by Putco.

07/08/2015 JLS

Fog Lamp Instructions

2004-2014 Ford F150 with round Fog Lamps

Contact your PUTCO dealer for other quality accessories.

KIT CONTENTS:

Tools Needed:

Flat bladed screwdriver

Qty.

3" #2 Phillips screwdriver

4RINST-F150

Table of Contents

Do you have a question about the LUMINIX and is the answer not in the manual?

Page 1 LIMITED 2 YEAR WARRANTY Putco guarantees it’s Stainless Steel and Aluminum products against defects in workmanship and material for as long as you own your vehicle. All painted products have a 90 day warranty on the painted surface. Any defects resulting from faulty material or workmanship will be warranted by Putco and repaired or replaced at our discretion.
Page 2 LIMITED 2 YEAR WARRANTY Putco guarantees it’s Stainless Steel and Aluminum products against defects in workmanship and material for as long as you own your vehicle. All painted products have a 90 day warranty on the painted surface. Any defects resulting from faulty material or workmanship will be warranted by Putco and repaired or replaced at our discretion.
Page 3 In some cases, factory fog lights will have a left and right side. Make sure to install spacer washer and the plastic insert into the correct tab on the Putco fog lamp as shown in Figure 4.
Page 4 Fog Lamp Installation 1. From the front side of the bumper connect the factory wiring harness to the Putco fog lamps. Ensure that connector is fully engaged and can not be pulled back apart. 2. Turn on the fog lamps to ensure everything is working properly.
