Interface and Key Description
Power Supply
The tester uses 4 x 1.5V Size AA alkaline batteries with power consumption
16mA. The batteries should be taken out if the tester does not use for a long
time to prevent the battery rack from leaking electrolyte corrosion.
Tester Panel and Port
AD8108
©Copyright Abacanto Digital SA.
LOOPBACK port
MAIN port
LCD display screen
power switch
function key
confirmation/return key
function key
