Atmel Xplained Pro SAM4L8 User Manual page 18

Pin on EXT5
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
Related Links
Xplained Pro Segment LCD Connector
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
SAM4L8 pin Function
PA18 SEG18
PA19 SEG19
PA20 SEG20
PB07 SEG21
PB06 SEG22
PA08 SEG23
PC24 SEG24
PC25 SEG25
PC26 SEG26
PC27 SEG27
PC28 SEG28
PC29 SEG29
PC30 SEG30
PC31 SEG31
PB12 SEG32
PB13 SEG33
PA21 SEG34
PA22 SEG35
PB14 SEG36
PB15 SEG37
PA23 SEG38
PA24 SEG39
- Not Connected
- Not Connected
- VCC_P3V3
- GND
PC05 Backlight
- ID
- GND
on page 12
Shared functionality
EXT3 and EXT4
EXT3 and EXT4
EXT3 and EXT4
EXT3
EXT1
EXT2 and EXT3
EXT2 and EXT3
EXT1 and EXT2
EXT1
EXT1
EXT1 and EXT2
EXT1 and EXT2
EXT2, EXT3, and EXT4
EXT2, EXT3, and EXT4
EXT1
EXT1
EXT2
Atmel SAM4L8 Xplained Pro [USER GUIDE]
Atmel-42103B-SAM4L8-Xplained-Pro_User Guide-04/2016
18
