Temperature Relays and MINIKA®
Operating Manual MS220Vi and MSR220Vi
- PTC Thermistor Relay
- TMP tripping device with circuit for temperature sensors in ignition protection type ex "i"
marking see type plate - EC-type-examination certificate PTB 07 ATEX 2055
MS220Vi and MSR220Vi
Mains Monitoring
Digital Panelmeters MINIPAN®
11910-0701-01
Switching Relays and Controls
Page 1 / 12
ZIEHL industrie – elektronik GmbH + Co KG
Daimlerstr.13, 74523 Schwaebisch Hall, Germany
+ 49 791 504-0, info@ziehl.de, www.ziehl.de
Measuring Transducers
Grid- and Plant Protection
updated: 2019-02-28 Su
www.ziehl.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ZIEHL MS220Vi
Summary of Contents for ZIEHL MS220Vi
- Page 1 ZIEHL industrie – elektronik GmbH + Co KG Daimlerstr.13, 74523 Schwaebisch Hall, Germany + 49 791 504-0, info@ziehl.de, www.ziehl.de Temperature Relays and MINIKA® Mains Monitoring Digital Panelmeters MINIPAN® Switching Relays and Controls Measuring Transducers Grid- and Plant Protection updated: 2019-02-28 Su...
-
Page 2: Table Of Contents
Start and Restart.......................... 10 14.7 Manual resetting .......................... 10 15 Proof testing of the safety functions ....................11 16 Maintenance and repair ........................11 17 EU – Declaration of Conformity ......................12 MS220Vi and MSR220Vi 11910-0701-01 Page 2 / 12 www.ziehl.de... -
Page 3: Display And Control Elements
Used in conjunction with respective PTC thermistors they provide a reliable temperature protection in the temperature range 60 °C up to 180 °C. ZIEHL PTC thermistor relays are conform to EN 60947-8. PTC-thermistors according DIN 44081 and DIN 44082 shall be connected. PTC thermistors are suitable for the installation into windings of electrical machines, bearings and transformers as well as to monitor the temperature of coolant, airflow and gases. -
Page 4: Summary Of Features
= area of potentially explosive atmosphere = Thermistor sensor = supply voltage = external Reset = pushbutton OFF = pushbutton ON = trip alarm F1-F4 = fuses = contactor 1) only MSR 2) twisted lines MS220Vi and MSR220Vi 11910-0701-01 Page 4 / 12 www.ziehl.de... -
Page 5: Functional Diagram
The devices must be installed in a closed switchgear cabinet or in an enclosure of international protection class IP 5x according EN 60529 or better. • Terminals with screw mounting M3 maximum tightening torque 0,5 Nm MS220Vi and MSR220Vi 11910-0701-01 Page 5 / 12 www.ziehl.de... -
Page 6: Commissioning
With no PTC sensor connected the PTC Trip Relay must release. The voltage at terminals T1-T2 must be approx. 8 V. In case of any other malfunctions, replace the device. Please add a description of the occurred malfunction when sending back for repair. MS220Vi and MSR220Vi 11910-0701-01 Page 6 / 12 www.ziehl.de... -
Page 7: Technical Data
Ue = 250 V DC13 Ie = 2 A Ue = 24 V Recommended fuse 4 A (gG) Mechanical contact life 3 x 10 operations Electrical contact life 1 x 10 operations MS220Vi and MSR220Vi 11910-0701-01 Page 7 / 12 www.ziehl.de... - Page 8 1 x 1,5 ... 4,0 mm (AWG 14 - 10) Stranded wire with insulated ferrules 1 x 1,5 ... 4,0 mm (AWG 14 - 10) Insulation strip length min. 6 mm Subject to technical modifications MS220Vi and MSR220Vi 11910-0701-01 Page 8 / 12 www.ziehl.de...
-
Page 9: Dimensions - Design V4
The relay may be installed only outside potentially explosive atmospheres. Within potentially explosive atmospheres the equipment is to be provided with a dust proofed enclosure according to EN 60529. MS220Vi and MSR220Vi 11910-0701-01 Page 9 / 12... -
Page 10: Wiring
The manual resetting may be only possible, if all safety functions and protection devices are effective. Trip device type MSR has an electronic reclosing lock. The stop instruction remains, until pressing the push- MS220Vi and MSR220Vi 11910-0701-01 Page 10 / 12... -
Page 11: Proof Testing Of The Safety Functions
The device must not be repaired from the user and replaced by a similar device. You’ll find this and other user manuals in the internet under www.ziehl.com ZIEHL industrie – elektronik GmbH + Co KG Daimlerstr. 13 74523 Schwaebisch Hall Germany Fon + 49 791 504-0 info@ziehl.de... -
Page 12: Eu-Declaration Of Conformity
17 EU-Declaration of Conformity EU-Declaration of Conformity Erklärung/Declaration No. 11915-1300-02 Hersteller: Ziehl industrie-elektronik GmbH + Co KG Manufacturer: Anschrift: Daimlerstr. 13 Address: 74523 Schwäbisch Hall Germany Produktbezeichnung: Kaltleiter-Relais Product specification: PTC Thermistor relay Typ: MS220Vi T222181 T222185 Type: MSR220Vi T222191 T222195 Wir erklären in alleiniger Verantwortung, dass...
