- Page 1 ZIEHL industrie – elektronik GmbH + Co KG Daimlerstr.13, 74523 Schwäbisch Hall, Germany + 49 791 504-0, info@ziehl.de, www.ziehl.de Temperature Relays and MINIKA® Mains Monitoring Digital Panelmeters MINIPAN® Switching Relays and Controls Grid- and Plant Protection Measuring Transducers updated: 2022-12-12 / nm...
-
Page 2: Table Of Contents
15.11 Manual reset .......................... 10 16 Proof testing of the safety functions ....................10 17 Maintenance and repair ........................11 18 Disposal ............................11 19 EU / UK -Declaration of conformity ....................12 MS220VA and MSR220VA 11660-0701-05 Seite 2 / 12 www.ziehl.de... -
Page 3: General Notes
Reset temperature 1 thermistor TNF + 15 K TNF + 5 K TNF – 5 K 3 thermistors in series TNF + 5 K TNF – 20 K 6 thermistors in series MS220VA and MSR220VA 11660-0701-05 Seite 3 / 12 www.ziehl.de... -
Page 4: Application And Brief Description
6 Connecting diagram PTC thermistor Supply voltage Off switch Push button on Remote reset Indicator lamp fault F1 – F4 Fuses Contactor *1 external interlock See chapter 15.11 *2 Manual reset Only MSR MS220VA and MSR220VA 11660-0701-05 Seite 4 / 12 www.ziehl.de... -
Page 5: Function Diagram
7 Function diagram MS220VA (automatic reset) MSR220VA (reclosing lock) Detector or line short-circuit Caution! The relay switches on automatically after a supply voltage dip. With a bridge at the reset input (Y1/Y2) the reclosing lock is out of operation. The device switches back automatically, when the temperature of the thermistor circuit has fallen below the switchback value. -
Page 6: Commissioning
Collective resistance cold thermistor ≤ 2.5 VDC at R ≤ 3.65 kΩ, ≤ 2 V at R ≤ 1.65 kΩ Terminal voltage (PTC thermistor) ≤ 9 VDC at R = Open-circuit voltage MS220VA and MSR220VA 11660-0701-05 Seite 6 / 12 www.ziehl.de... - Page 7 IP 30 Mounting EN 60715 Snap mounting on 35 mm standard rail EN60715 Optional: Screw mounting M4 screws (additional bar not included) Weight approx. 117 g Terminal connection Screw mounting M3 MS220VA and MSR220VA 11660-0701-05 Seite 7 / 12 www.ziehl.de...
-
Page 8: Dimensions - Design V2
15.3 Special remarks for use in the presence of combustible dust (Zone 20, 21 and 22) • The device must be installed outside potentially explosive dust atmospheres unless the device is pro- tected by a suitable enclosure for dust atmospheres. MS220VA and MSR220VA 11660-0701-05 Seite 8 / 12 www.ziehl.de... -
Page 9: Safety Characteristics Of The Safety Device (En 50495/Vde 0171-18)
With commissioning and after modification of the plant the thermistor resistance must be checked with a suitable measuring instrument. With a resistance < 50 Ω the sensor circuit is to be examined for short-circuit. Attention! Check PTC’s only with measuring voltages of < 2.5 V. MS220VA and MSR220VA 11660-0701-05 Seite 9 / 12 www.ziehl.de... -
Page 10: Safe Separation
For the device type MSR the function of the electronic interlock must be tested additionally. • If an error is detected no restart must be induced until the error is cleared. MS220VA and MSR220VA 11660-0701-05 Seite 10 / 12 www.ziehl.de... -
Page 11: Maintenance And Repair
Disposal should be carried out properly and in an environmentally friendly manner in accordance with legal provisions. ZIEHL is registered with the EAR Foundation under WEEE no.: DE 49 698 543 You will find this and other user manuals written in English under www.ziehl.com... -
Page 12: Eu / Uk -Declaration Of Conformity
19 EU / UKCA -Declaration of conformity EU / UKCA-Konformitätserklärung EU / UKCA-Declaration of Conformity Hersteller: ZIEHL industrie-elektronik GmbH + Co KG Manufacturer: Anschrift: Daimlerstr. 13 Address: 74523 Schwäbisch Hall Germany Produktbezeichnung: Kaltleiter-Relais Product description: PTC Thermistor Relay Typ: MS220VA...
