Overview page: Clicking the padlock symbol will unlock or lock this over-
view page for editing. Device: Device can not be used due to update ser-
vice problems, see "Updates and update service" for details.
Clicking the gear symbol will access the basic configuration page of the
selected list element.
In order to save all settings into a device, click the disk symbol in the
headline.
This symbol indicates that communication with this device is not possible
at the moment. Check USB connection and power supply of the device if
necessary.

7. 7. 7. 7. Overview pages (aquasuite)

Overview pages (aquasuite) Overview pages (aquasuite) Overview pages (aquasuite)
Current sensor readings and diagrams from all supported devices can be dis-
played in overview pages. For each device a pre-configured overview page is au-
tomatically generated the first time the device is connected to the PC. These pages
can be individually modified and new pages can be created. Within one overview
page, data from all connected devices can be accessed.

7.1. Desktop mode

7.1. Desktop mode
7.1. 7.1. Desktop mode Desktop mode
Each overview page can be displayed directly on your desktop. You can enable
desktop mode for an overview page by clicking the monitor symbol in the list of
overview pages. Desktop mode can only be enabled for one overview page at a
time. With desktop mode enabled, elements of the overview page may cover pro-
gram symbols on your desktop, but mouse clicks are transmitted to underlying
desktop symbols.
If a overview page is unlocked for editing while desktop mode is active, the page
will be displayed in the aquasuite window for editing and the current desktop will
be displayed as background for your convenience.

7.2. Creating new overview pages and activating edit mode

7.2. 7.2. 7.2. Creating new overview pages and activating edit mode Creating new overview pages and activating edit mode Creating new overview pages and activating edit mode
In order to create a new overview page, click the plus symbol in the headline
"Overview pages".
Existing overview pages can be unlocked for editing by clicking lock symbol in the
page listing.

7.3. Adding new elements

7.3. Adding new elements
7.3. 7.3. Adding new elements Adding new elements
If the currently selected overview page is unlocked for editing, a plus symbol is dis-
played in the top right corner of the screen. Click the symbol to add a
new element to the page and select the desired element from the follow-
