OCTO
Existing LED controllers can be moved by using "drag&drop"on the corre-
sponding color bars. The position of the color bar defines the position of
the effect on the connected LEDs. Controllers positioned further up in the
list have higher priority than controllers further below.
The length of the bar (corresponding to the number of LEDs assigned) can be
changed by moving the right/left edge of the color bar.

11.4. Duplicate LED controllers

11.4. Duplicate LED controllers
11.4. 11.4. Duplicate LED controllers Duplicate LED controllers
Select the LED controller(s) to be duplicated and click the duplicate sym-
bol to create new LED controllers using identical configurations. Alterna-
tively, use the right mouse button and select "Duplicate" from the context
menu.
These duplicated controllers will initially have configurations identical to the origi-
nal controllers, but can be modified without affecting the original controllers.
In total, up to 6 LED controllers can be configured for each output.

11.5. Delete LED controllers

11.5. 11.5. 11.5. Delete LED controllers Delete LED controllers Delete LED controllers
Select the LED controller(s) to be deleted and click the delete symbol to
delete the selected controllers. Alternatively, use the right mouse button
and select "Delete" from the context menu.

11.6. Sound controlled effects

11.6. Sound controlled effects
11.6. 11.6. Sound controlled effects Sound controlled effects
Sound controlled effects can be used to visualize the current audio output of the
computer. A warning in the LED configuration area will notify you if audio analysis
has been disabled in the aquasuite. In this case, please enable the feature in the
general aquasuite configuration. The general aquasuite configuration can also be
used to modify existing audio filters and define custom audio filters.
11.7. 11.7. 11.7.

11.7. AMBIENTpx effect

AMBIENTpx effect AMBIENTpx effect AMBIENTpx effect
The AMBIENTpx effect replicates the border area of the current monitor content on
the configured LEDs. This effect is meant to be used with LED strips installed to the
rear of the monitor for background lighting. A warning in the LED configuration
area will notify you if video analysis has been disabled in the aquasuite. In this
case, please enable the feature in the general aquasuite configuration.
For each configured AMBIENTpx effect, please select the correct monitor, edge
and desktop range to evaluate for the effect.
Prerequisites and limitations:
The AMBIENTpx effect requires Microsoft Windows operating system version
●
8.1 or newer.
Screen content preventing analysis by DRM or similar methods cannot be
●
analyzed.
