checked) or remain active at the set minimum speed (box checked). Set minimum
power to a value at which the connected fan reliably starts up.
The "Maximum fan speed for bar graph and chart" setting applies only to diagram
scaling within the aquasuite and has no effect on the fan output.

10.5. Fan behavior with aquabus connection to an aquaero

10.5. Fan behavior with aquabus connection to an aquaero
10.5. 10.5. Fan behavior with aquabus connection to an aquaero Fan behavior with aquabus connection to an aquaero
As soon as an aquabus connection between the OCTO and an aquaero 5/6 is
established, the fan output is solely controlled by the aquaero. All settings in the
OCTO regarding fan function will be ignored. Only if aquabus is disconnected,
the settings in the OCTO will be used for controlling the fan output again.

11. RGBpx configuration

11. 11. 11. RGBpx configuration RGBpx configuration RGBpx configuration
Select "RGBpx" from the device list below the "OCTO" entry.
In the RGBpx overview, select the RGBpx output to be configured.
After selecting a RGBpx output, new LED controllers can be added. Posi-
tion and number of assigned LEDs can be modified for existing LED controllers,
controller settings can be modified.
11.1. 11.1. 11.1.

11.1. Create and configure additional LED controllers

Create and configure additional LED controllers Create and configure additional LED controllers Create and configure additional LED controllers
After selecting a RGBpx output, new LED controllers can be added by
clicking the plus symbol. Alternatively, use the right mouse button and se-
lect "New" from the context menu. Select the desired effect from the su-
perimposed list of available effects. The controller name can be altered from its
default as well. Confirm you selection by clicking the check symbol in the lower
right corner.
The configuration of the newly added LED controller can be modified in the lower
area of the window. Each LED controller can activated or deactivated for each of
the four available profiles as well. Most effects offer extensive customization op-
tions such as color selection or speed adjustment. Additionally, many effects can
be configured to modify effect parameters depending on current sensor data.
In total, up to 6 LED controllers can be configured for each output.
11.2. 11.2. 11.2.

11.2. Modify existing LED controllers

Modify existing LED controllers Modify existing LED controllers Modify existing LED controllers
Existing LED controllers can be selected by clicking the corresponding col-
or bars, the configuration of the selected controller can then be modified
in the lower area of the window.
By clicking the gear symbol, the effect to be displayed can be changed and the
controller name can be altered. Confirm you selection by clicking the check sym-
bol in the lower right corner.
11.3.

11.3. Modify LED assignments

Modify LED assignments
11.3. 11.3. Modify LED assignments Modify LED assignments
