OCTO

13.1. Manual profile selection

13.1. 13.1. 13.1. Manual profile selection Manual profile selection Manual profile selection
Select the profile to be activated by clicking the corresponding button.

13.2. Automatic profile selection

13.2. Automatic profile selection
13.2. 13.2. Automatic profile selection Automatic profile selection
Profiles can be activated automatically using the global profiles feature of the
aquasuite, see chapter 15.2. for details.
13.3.

13.3. Profile configuration

Profile configuration
13.3. 13.3. Profile configuration Profile configuration
All configuration changes are automatically stored in the currently active profile.
The current configuration can also be stored in any other profile by clicking the
corresponding button.
14. 14. 14.

14. System settings OCTO

System settings OCTO System settings OCTO System settings OCTO
Select "System" from the device list below the "OCTO" entry.

14.1. Device information

14.1. 14.1. 14.1. Device information Device information Device information
The details displayed here might be required when you contact our service for sup-
port. You may enter a "Device description" for easier identification, this text will be
displayed in the device list and in the data quick view.

14.2. Factory defaults

14.2. 14.2. 14.2. Factory defaults Factory defaults Factory defaults
Click the button "Reset device to factory defaults" in the aquasuite or select the
"Factory defaults" entry from the menu for a complete reset of all settings. You will
have to completely reconfigure the device after resetting it to factory defaults!
14.3.

14.3. Basic RGBpx settings

Basic RGBpx settings
14.3. 14.3. Basic RGBpx settings Basic RGBpx settings
Both RGBpx outputs can be completely disabled and the brightness of both out-
puts can be adjusted using a slider.
14.4. 14.4.

14.4. Firmware update

14.4. Firmware update Firmware update Firmware update
The most up to date firmware for all supported devices is always included in the
current version of the aquasuite software. The button " Update firmware now" will
start the update process for the device firmware.
During the firmware update process, do not disconnect the device from the PC
and do not power down the PC! After the firmware is successfully updated, the
aquasuite software will be automatically closed.
