16.2. Bluetooth pairing

16.2. 16.2. 16.2. Bluetooth pairing Bluetooth pairing Bluetooth pairing
Before the farbwerk demo app can access farbwerk devices via Bluetooth, each
farbwerk device must be paired with your mobile device. Open the app drawer
and go to "Settings". In the settings screen, select "Bluetooth". The farbwerk Blue-
tooth devices will show as "farbwerk xxxxx-xxxxx", where xxxxx-xxxxx will be re-
placed by the individual serial number of each farbwerk device. See chapter 12.1.
for reference.
Tap the farbwerk device you want to pair to your mobile phone and enter the pair-
ing key for the farbwerk device. Factory default key is "1234", see chapter 12.4.
for individual configuration.
16.3.

16.3. Using the Android demo app

16.3. 16.3. Using the Android demo app Using the Android demo app Using the Android demo app
Open the app drawer and go to "farbwerk". The farbwerk demo app will display a
list of all paired farbwerk devices. Tap any device to access the settings for this de-
vice.
Please note: Each output has to be configured to use an "External controller
source" to accept configuration via Bluetooth. Please see chapter 10.1. for refer-
ence.
Please note: Only one mobile device can be connected to a farbwerk device via
Bluetooth at any given time. After leaving the settings screen in the farbwerk demo
app, other devices can connect to this controller via Bluetooth again.

17. Technical details and care instructions

17. Technical details and care instructions
17. 17. Technical details and care instructions Technical details and care instructions
17.1. 17.1. 17.1.

17.1. Technical details

Technical details Technical details Technical details
Dimensions W x H x D:
Power supply voltage:
Power supply current:
LED output voltage:
Output current per channel:
Combined output current:
Ambient temperature range:
Bluetooth interface

17.2. Care instructions

17.2. 17.2. 17.2. Care instructions Care instructions Care instructions
Use a dry and soft cloth for cleaning. All electronic components and headers must
not get in contact with coolant or water!
© 2014-2020
47 mm x 41 mm x 20 mm
12 V DC ±5 %, 5 V DC ±5 %
max 8.1 A
12 V
max. 2.5 A at 12 V
max. 8 A at 12 V
10 to 40 °C (noncondensing)
Bluetooth class 1, max. 10 m, SPP protocol
(Bluetooth version only)
