Using Vivo
• The automated changes can be overridden, thereby making the orange highlights
disappear
• The automated changes will return to the previous values when the associated control
has been removed
• For parameters with a left and right option (lungs, eyes) the left and right parameters can
be adjusted independently or together
For example, tap on either side or both sides of the Patient Vitals Lungs tile to highlight
the selection.
• Tiles with a notes icon allow for data capture. Tap the tile to open the data capture
window
136
The Tiles With Automated Physiology Highlight
The Tile with One Side Highlighted
CAEAthena
The highlighted side
PN: 905K520652 v2.8
The
orange
highlight
