Quick Start for 3G+ Modem/Router with Phone Port
This Quick Start describes setup for the Modem/Router. First the Modem/Router is configured using a
®
®
Windows
, Macintosh
choose. More detailed information is in the User Manual on the CD

Package Contents

The package contains the Modem/Router, a 12V 1.0A Power Adapter, an Ethernet Cable, this Quick
Start flyer, and a CD that contains additional documentation and warranty information. If anything is
missing or damaged, please contact Zoom Customer Support or whoever provided the
Modem/Router.

Getting Started

This Quick Start describes setting up the Modem/Router to use its built-in 3G+ mobile broadband
modem to provide Internet access and voice calls using a mobile broadband service. Please see the
full-length manual on your CD if you want to use the Modem/Router to back up your existing DSL or
Cable connection.
Before installing the Modem/Router you will need a SIM card for the built-in 3G+ modem. This
SIM card may have been provided to you by your service provider or you may need to purchase one.
To use the Modem/Router for both data and voice you will need a SIM that supports both data and
voice. If you just want to use the Modem/Router for Internet access, a SIM that only supports data
will work.

Installing the Hardware

1 Place the Modem/Router near a computer to be used for setup. This computer needs an Ethernet (LAN)
port.
2 Turn off the computer.
3 Attach the antenna to the Modem/Router if the antenna isn't already attached. (Remove the antenna from
the package. Place the end of the detachable antenna on the open antenna connection port and rotate
the antenna clockwise by hand until it no longer turns easily. It may take many turns before the antenna is
completely connected. Move the antenna into an upright orientation, since that normally gives best
wireless performance. The antenna should snap into place.
4 Insert the SIM card into the slot on the back of the modem as shown below. You should hear the SIM
card click into place.
i.
, or Linux computer; and then the Modem/Router is connected to the devices you
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zoom 4530

  • Page 1 The package contains the Modem/Router, a 12V 1.0A Power Adapter, an Ethernet Cable, this Quick Start flyer, and a CD that contains additional documentation and warranty information. If anything is missing or damaged, please contact Zoom Customer Support or whoever provided the Modem/Router.
  • Page 2 5 Connect one end of the supplied Ethernet cable to any of the computer’s Ethernet ports and the other end to any of the Modem/Router‘s LAN ports. 6 Plug the supplied power cube into the Modem/Router and then into a power outlet. The Modem/Router has completed powering up when the Status light starts blinking.
  • Page 3 Channel: The default channel is set to 10. This is fine for most users. In the unlikely event that you experience performance issues with your wireless network, you may want to set your network up on a channel that is different from the factory-set channel of 10. For instance, you may want to try channel 1 or 6.
  • Page 4 “Wireless network detected. Click here for available networks.” The name of the Modem/Router’s wireless network (SSID) is found on the bottom label of your unit. The default Wireless Network name is Zoom- followed by 6 random characters unless you changed the name during installation. When your client device pro...
  • Page 5 This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022/A1 Class B. Zoom Telephonics, Inc. hereby declares that this router is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The complete Declaration of Conformity is available in the full length manual on the CD or at www.zoomtel.com/compliance.
