Labels And Markings - Falltech 7262 Instructions Manual

Component
Housing
Drum
Main Shaft
Pawls/Ratchet
Webbing
Attachment Connector(s)
* When tested in accordance with ANSI Z359.1‐2007
10.3: Labels and Markings
The labels shown below must be present on the product and must be legible. If
labels are not present and legible, remove the product from service.
Model #s: 7276WR
Nylon 6/6 over Alloy Steel
Aluminum
Alloy Steel
Alloy Steel
Dyneema®
Chro‐Moly Alloy Steel
* Deceleration Distance: < 24"
Fig. 10.1
Labels for FallTech Web Retractor
7262, 72624, 7263 and 8262
(Located on webbing above hook)
19
Material
Overall static strength: > 3,000 lbs
* Arrest Forces: < 900 lbs
Maximum Capacity: 310 lbs
Rating
3,000 lbs
n/a
3,000 lbs
n/a
4,500 lbs
5,000 lbs
