To be the Chief Evangelist
Ender-5 Pro Printer
Guide Book
To make Top-quality 3D printer
◆ This guide book is for standard Ender-5 Pro.
◆ Please plug the power cord into a three-hole power jack.
◆ Detailed instructions for use are available in the TF card.
V.2.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ender-5 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Creality Ender-5 Pro

  • Page 1 Ender-5 Pro Printer Guide Book To make Top-quality 3D printer ◆ This guide book is for standard Ender-5 Pro. ◆ Please plug the power cord into a three-hole power jack. ◆ Detailed instructions for use are available in the TF card.
  • Page 2: Table Of Contents

    For a better experience in using our product, you may learn how to use the Printer in the following ways: 1. View the accompanied instructions and videos in the TF card. 2. Visit our official website www.creality. com You will find relevant software/hardware information, contact details and operation and maintenance instructions on the website.
  • Page 3 Notes Do not use the printer any way other than described herein in order to avoid personal injury or property damage. Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment. Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.
  • Page 4: Introduction

    A、 Introduction 1.Hot Bed 5.SD Slot and USB Port 9.Spool Holder 13.Y Stepper 2.Levelling screw 6.Display 10.Extrusion mechanism 14.Z Limit Switch 3.Power supply 7.Z Stepper 11.X Stepper 15.Y Limit Switch 4.Switch 8.Foot pad 12.Nozzle Assembly 16.X Limit Switch...
  • Page 5: General List

    B、 General List Tool List A:Top Frame Image Name Wrench & Screw 1set driver B:Z-axis Frame TF Card & Reader 1set Spatula 2040 Profile 4Pcs Pliers D:Extruder kit 0.4mm Nozzle Cleaner Power Cable E:Filament Holder Filament(200)g F:Hot Bed Spare Parts 1set 2pcs 2pcs...
  • Page 6: Assembly Step

    C、 Assembly Step 8pcs M5X25 4pcs 2040 Profile Place the profile hole of the side upon, install the profile, but Bottom Frame not mess with the direction.
  • Page 7 8pcs M5X25 Note: Tighten the four screws on the top, then tight the side screws.
  • Page 8 4pcs M5X30 Note: Align the Z-axis Frame bottom profile ,then tighten the screws.
  • Page 9 Hot Bed M4X10 6pcs...
  • Page 10 M4X8 M4X8 M4X8 M4 T-nut M4X8 M4 T-nut M5X8 M5 T-nut 2pcs 2pcs 2pcs 2pcs 2pcs...
  • Page 11: Cable Connection

    D、 Cable Connection Exp3...
  • Page 12 Nozzle Cable Connection Bed Cable Connection *Plug the power cord into a three-hole power jack.
  • Page 13: Screen Information

    Current Temperature Print Speed of the Nozzle Model Set Temperature of the Hot Bed CurrentTemperature of the Hot Bed Ender-5 Pro Part Cooling Fan Speed Current Location of the nozzle Print Time Ender-5 Pro Print Progress Prompt Message Push:OK/Enter Sub Menu...
  • Page 14: Loading Filament

    F、 Loading Filament 1. Preheat Method 1 Method 2 Method 2 2. Feeding 2. Feeding Tip:How to Replace the Filament? 1、Cutting filament near the Extruder and slowly feed new filament until they are fed into the new filament. 2、Preheating the nozzle and withdraw the filament quickly and feed the new filament.
  • Page 15: Bed Levelling

    G、 Bed Levelling 1. Prepare →Auto Home. Wait for the nozzle to move to the left/front of the platform. 2. Prepare→Disable Steppers(Close stepper drive,release motor) 3. Move the nozzle the front/left leveling screw and adjust the platform height by turning the knob underneath. Use a piece of A4 paper (standard printer paper) to assist with the adjustment, making sure that the nozzle lightly scratches the paper.
  • Page 16: Software Installation

    H、 Software Installation 1. Double click to install the software. 2、Double click to 3. Select language→Next→Select your machine→Next→Finish. open the software.
  • Page 17: P R E P A R I N G T O P R I N

    I、 Preparing to Print 1.Slicing Insert TF card into computer with Reader. Open the software→Load→Select the file→Wait for slicing to finish ,and save the gcode file to TF card. 2.Printing Insert the TF card→Select Print from TF →Select the file.
  • Page 18: Troubl E S H O O T I N

    J、 Trouble shooting...
  • Page 19 3d industry and establishing a good image of 3d printing, since Creality 3d printer have passed all kinds of authorized 5. Not included in warranty coverage: product certificates and quality management system.hereby we declare   (1) It is not possible to provide an effective after-sales service card or...
  • Page 20 SHENZHEN CREALITY 3D TECHNOLOGY CO.,LTD. 11F & Room 1201,Block 3,JinChengYuan,Tongsheng Community, Dalang,Longhua District,Shenzhen,China,518109 Official Website: www.creality.com Tel: +86 755-8523 4565 E-mail: info@creality.com cs@creality.com...
