- Page 1 Quick Start Guide i.MX 6SLL Evaluation Kit Arrow.com. Downloaded from...
- Page 2 Quick Start Guide ABOUT THE i.MX 6SLL EVALUATION KIT The following features are available with the EVK based on i.MX 6SLL applications processor: i.MX 6SLL applications processor with a EPDC expansion port (unpopulated) 1 GHz ARM Cortex -A9 core ®...
-
Page 3: Getting Started
GETTING STARTED The i.MX 6SLL EVK includes the following items: Board: MCIMX6SLL-EVK Cables: USB AM TO MICRO USB 5P 1.0M Power supply: 100/240 V input, 5 V, 4 A output Documentation: Quick Start Guide (this document) ... - Page 4 Quick Start Guide GET TO KNOW THE i.MX 6SLL EVK Power Booth Device Debug Switch Host Switches 5V Power Jack Boot Mode Switch Audio Jack SPK Out PMIC EMMC Figure 1: Front side of i.MX 6SLL EVK (top) Arrow.com. Arrow.com. Arrow.com.
- Page 5 www.nxp.com i.MX 6SLL applications processor JTAG LPDDR3 ON/OFF RESET Bluetooth Figure 2: Back side of i.MX 6SLL EVK (bottom) Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
-
Page 6: Setting Up The Board
Quick Start Guide SETTING UP THE BOARD Note: The PC needs a driver to enable Insert SD a virtual COM port through the PC USB Card port. Insert the supplied SD card into the SD1 Visit ftdichip.com/drivers/vcp.htm to card slot. download the correct driver. - Page 7 www.nxp.com BOOT PROCESS FOR LINUX IMAGE Boot Process Change S1 to enter internal boot When the boot process is complete, mode (BOOT_MODE [1:0] = 10), and the Linux operating system (Yocto then switch SW3, SW4, SW5 to boot Project) will be displayed on the LCD from the SD1 card, as shown in Table1 screen.
- Page 8 Quick Start Guide BOOT OPTIONS AND SWITCH CONFIGURATION Table 1 shows the switch configuration of boot mode for i.MX 6SLL EVK. Internal boot is chosen as default. Table 2 shows the switch configuration of boot device for i.MX 6SLL EVK. SD1 is chosen as default.
- Page 9 www.nxp.com JUMPER, PUSH BUTTONS AND SWITCHES CONFIGURATION Reference Shunt Installation Function Use cable to pins 1 and 2 to connect an external 1–2 charger 2–3 Shunt 2–3 to experiment with USB charging OpenD No charger 1–2 5 V rail supplied by PMIC (600 mA limited) 2–3 5 V rail supplied from wall adapter 1–2...
-
Page 10: Tips And Precautions
5.5 V. The user must take into account this is the maximum voltage that can be plugged into J6. FURTHER DOCUMENTATION MCIMX6SLL-EVK schematics MCIMX6SLL-EVK BOM MCIMX6SLL-EVK gerber files MCIMX6SLL-EVK reference manual Complete documentation is available at www.nxp.com/iMX6SLLEVK Arrow.com. Arrow.com. - Page 11 www.nxp.com Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
-
Page 12: Warranty
SUPPORT Get Started Visit the i.MX community at Download installation www.imxcommunity.org. software and documentation WARRANTY under “Getting Started” at www.nxp.com/iMX6SLLEVK. Visit www.nxp.com/warranty for complete warranty information. www.nxp.com/iMX6SLLEVK NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
