- Page 1 Quick Start Guide SABRE Board for Smart Devices Based on the i.MX 7Dual Applications Processor SMART APPLICATION BLUEPRINT FOR RAPID ENGINEERING (SABRE)
- Page 2 Quick Start Guide GET TO KNOW SABRE BOARD FOR SMART DEVICES BASED ON THE i.MX 7DUAL SW1–Power J12–JTAG Switch Connector J1–5 V DC Power Connector J11-Debug UART via USB D1–Power J32, J33–mikroBus™ on LED Socket J13–EPD Controller J7–SIM Card Slot J18–Smart Card Interface U10–eMMC...
- Page 3 www.nxp.com U11–64 MB QSPI Flash J30–MIPI- J8–Mini- ® DSI Display PCIe Socket U12-NAND expansion J6–SD J3–Coin Battery Card Socket backup for SNVS (Secure Nonvolatile Storage) J14–Parallel LCD Display Figure 2. Bottom View of the i.MX 7Dual SABRE board...
- Page 4 Quick Start Guide GET TO KNOW SABRE BOARD FOR SMART DEVICES BASED ON THE i.MX 7DUAL PROCESSOR The Smart Application Blueprint for The development kit provides an Rapid Engineering (SABRE) board for out-of-box working demonstration to smart devices introduces developers power-on and run an operating system to NXP’s new heterogenous multi- from an SD card, exercising the features...
- Page 5 www.nxp.com FEATURES The following features are available with the i.MX 7Dual SABRE board for smart devices: • i.MX 7Dual applications processor - 802.11 a/b/g/n/ac Wi-Fi on board - Two ARM Cortex-A7 cores - Bluetooth V4.0 + EDR on board ® operating up to 1 GHz •...
- Page 6 Quick Start Guide STEP-BY-STEP INSTRUCTIONS This section describes how to use the Insert SABRE board for smart devices and the SD Card components in the box. This section also describes the PC requirements to Insert the supplied SD card into the SD develop applications using the SABRE card slot (J6).
-
Page 7: Debug Uart
www.nxp.com Connect to Connect User Interface Debug UART Devices (Optional) Connect the micro-B end of the supplied Connect monitor via the HDMI connector USB cable to Debug UART port (J11) (J9). To interact with the user interface and the other end of the cable to PC displayed on the monitor it may be desirable acting as the host terminal. -
Page 8: Tips And Precautions
Quick Start Guide BOOT PROCESS FOR LINUX IMAGE During the boot process, there will be To work from the terminal window on operating system status information the host PC, press enter at the terminal scrolling on the terminal window of the window to get the command prompt. -
Page 9: Further Documentation
www.nxp.com FURTHER DOCUMENTATION • i.MX 7Dual SABRE Board schematics • i.MX 7Dual SABRE Board BOM • i.MX 7Dual SABRE Board gerber files • i.MX 7Dual SABRE Board reference manual For complete documentation, please refer to www.nxp.com/iMX7DSABRE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 10 Note 1、The grantee is responsible for ensuring through appropriate testing and clear instructions of use contained in the instruction manual that the host manufactures product is compliant to all the applicable FCC rules. The installer must to perform tests inside of each host for the host manufactures product(s) are compliant to all the applicable FCC rule.
-
Page 12: Warranty
SUPPORT Get Started Visit i.MX community at www.imxcommunity.org. Further design resources and documentation under WARRANTY “Jump Start Your Design” Visit www.nxp.com/warranty for at www.nxp.com/iMX7DSABRE. complete warranty information. www.nxp.com/iMX7DSABRE NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
