TOWER SYSTEM TOWER SYSTEM Introduction This lab is a step-by-step guide to run NOTE: Please refer to the MED-EKG schematic for circuit detail. The schematic is included in the DVD. Stages 6 and 7 the EKG demo. The EKG demo uses may not be necessary in your own EKG application.
Page 3
Lab Tutorial for TWR-S08MM128-KIT TOWER SYSTEM Get to Know the MED-EKG Ensure J2 jumper is Connections to the installed as indicated. S08MM128 analog modules and power source from the Tower This green LED will System. The power illuminate to indicate switch is controlled that the MED-EKG is by the S08MM128 pin...
TOWER SYSTEM Step-by-Step Guide Configuring the Hardware 4. On the TWR-S08MM128 module, remove the jumpers that connect pins 1 and 2, 9 1. Assemble the Tower System and configure and 10, 11 and 12, and 13 and 14 from the jumpers to the default settings as header J18.
Lab Tutorial for TWR-S08MM128-KIT TOWER SYSTEM Connecting to the Computer 6. Connect the first USB cable to the computer and the mini-USB connector on the TWR-SER module. If Windows asks for a driver at this point, cancel it. We will load the proper driver later in the lab.
Page 6
TOWER SYSTEM 11. On the final screen, click “Finish.” The 14. In the CodeWarrior menu, select File > OSBDM driver is now loaded. Open. Then, browse to the following path and file: d:\work\LAB1\MEDEKGSW\SW for MM devices\ECG for S08MM\Ecg for S08MM.mcp 15.
Page 7
Lab Tutorial for TWR-S08MM128-KIT TOWER SYSTEM Installing the MED EKG GUI 22. When installation is complete, click the “Finish” button. 18. Microsoft .NET Framework 2.0 (support up to Windows XP) or 3.5 (support up to Installing the Windows 7) is required to run the MED-EKG GUI.
Page 8
TOWER SYSTEM 25. When asked “What do you want the wizard 27. If you see the following dialog box, click to do?” click “Install from a list or specific “Install this driver software anyway.” location.” 28. When the installation is complete, click “Finish.”...
Page 9
Lab Tutorial for TWR-S08MM128-KIT TOWER SYSTEM Running the MED-EKG DEMO 31. Select the COM port number found in Step 29. Then, click the “Start” button. You 29. Once the CDC driver installation is will see the GUI start to display a random complete, find the exact COM port that waveform.
Page 10
TOWER SYSTEM 33. Wait for signal stabilization (about 10 34. If the signal varies, try different finger seconds), avoiding movements and with positions, but wait for stabilization time relaxed respiration. The heart rate is (usually 10 seconds). Experiment with this similar shown in the red highlighted box below.
Page 11
Lab Tutorial for TWR-S08MM128-KIT TOWER SYSTEM 36. If the “Display Raw Data” checkbox is selected, the graph’s data will be shown in the column on the right side. It may be useful to copy and paste the data to the spreadsheet for later analysis.
Page 12
TOWER SYSTEM Information in this document is provided solely to enable system and software implementers to use Freescale Semiconductor products. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits or integrated circuits based on the information in this document. Freescale Semiconductor reserves the right to make changes without further notice to any products herein.
