STEP 1
SuperPINDA adjustment (part 1)
Ensure the printer is turned off and not plugged in.
While moving with the extruder, the X-axis motor works as a generator. You will
create a small amount of electricity and the LCD might flicker. Move with the
extruder reasonably slowly and in the future always use the printer's controls.
Move the extruder manually all the way to the left.
By rotating BOTH threaded rods at the same time on the Z-axis move the nozzle
until you reach the heatbed. Try rotating both the rods equally!
Check again from a different angle the nozzle is touching slightly the heatbed.
Don't bend the heatbed!
Don't place the steel sheet on the heatbed during the entire SuperPINDA sensor
adjustment process. Wait for the XYZ calibration.
STEP 2
SuperPINDA adjustment (part 2)
Move the extruder carefully all the way to the right.
Make sure that the nozzle is not scratching the surface during the movement! If it
does, rise the right side of the X-axis by rotating the right Z motor (threaded rod)
slightly clockwise.
If an adjustment is needed, you can lower the nozzle height by rotating the right Z
motor (threaded rod) counter-clockwise.
9. Preflight check
Original Prusa i3 MK3S+ kit assembly
133
