quadient IN-360 Series Quick Installation Manual

IN-360 Series
Quick Installation Guide
Mailing System Components:
feeding table and
moistener
1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift the mailing system base (a) slightly on the left hand side and align the hooks to
attach the feeding table (b). Attach the catch tray (c)
mailing system base.
9
Installation Process
1 LAN
OK
Select LAN and press 'OK' to test connection type.
For more help with your installation, please visit:
mailing system
base
catch tray
back of mailing system base
2
Lift the cover of the mailing system
base (a) to reveal the meter (h) and ink
cartridge (i) bays.
6
d
Lower weighing platform release panel (tailgate)at rear of
to the right hand side of the
the mailing system base (a). Place weighing platform
on top of the mailing system base and slide forward to lock.
Lift release panelto secure and clip cable into place.
10
Installation Process
Press the 'Next' to start the
Online service
declaration.
Next
Complete the declaration by following the
steps on screen.
weighing platform (WP)
d
3
Open the meter cover. Place the meter (h) into the meter bay and slide
in until it fits securely into position. Close the meter cover.
7
Insert the WP connector
(d) system base (a). Then connect the LAN cable
(g) to each side of the mailing system.
11
Headset alignment
A C E G I K
Select letter with arrows
and press «OK»
B D F H J
It is recommended to follow screen prompts to test
ink alignment.
kb.quadient.us/in360
LAN cable power cable
weighing platform
(WP) connector
4
Insert the ink cartridge (i)
facing upwards. Push the ink cartridge
system until you hear a 'click'. Close the cover.
(e) into the port on the rear of the mailing
(f) and power cable
13
Amount
Postage available
$ 100.00
Enter Amount:
$ 10
Once back on the home screen, press the coins
button and then select '2' to add funds. Enter the
amount and then press the white check button.
meter
ink cartridge
Remove tabs from
print heads before
inserting into unit!
into ink bay with the 'TOP' and 'LOCK' stickers
(i) towards the back of the mailing
8
Turn on the mailing system base using the switch
behind the power cable (g) and follow the steps
on screen.
14
Your mailing system base is now ready to use.
