quadient IN-600 Series Quick Installation Manual

IN-600 Series
Quick Installation Guide
Mailing System Components :
feeding table
and moistener
1
Unpack all components from the box, remove packaging
and any transit tape.
5
Lift the mailing system base (a) slightly on the left hand side and align the hooks to attach the
feeding table (b). Attach the catch tray (c) to the right hand side of the mailing system base
9
Installation Process
1 LAN
OK
Select LAN and press 'OK' to test connection type.
For more help with your installation, please visit:
mailing
system base
catch tray
back of mailing system base
2
Lift the cover of the mailing system
base (a) to reveal the meter (h) and ink
cartridge (i) bays.
6
Attach the weighing platform
shelf
(a).
base
10
Installation Process
Press the 'Next' to start the
Online service
decliration.
Next
Complete the declaration by following the steps on
screen.
weighing platform
(WP)
weighing platform
(WP) connector
3
Place the meter (h) into the meter bay and push slide in until it fits
securely into position.
7
(d) and Insert the WP connector
(j) to the top of the mailing system
system base (a). Then connect the LAN cable
(a). (g) to each side of the mailing system.
12
Headset alignment
A C E G I K
Select letter with arrows
and press «OK»
B D F H J
It is recommended to follow screen
Once back on the home screen, press the coins
prompts to test ink alignment.
button to add funds to the meter.
kb.quadient.us/in600
LAN cable power cable meter
4
Insert the ink cartridge
facing upwards. Push the ink cartridge
system until you hear a 'click'. Close the cover.
(e) into the port on the rear of the mailing
(f) and power cable
13
Amount
Postage available
$ 100.00
Enter amount:
$ 10
Your mailing system base is now ready to use.
Please turn this sheet over for your Quick Start Guide.
ink cartridge
shelf
(i) into the ink bay with the 'TOP' and 'LOCK' stickers
(i) towards the back of the mailing
8
Turn on the mailing system base (a) using the
switch behind the power cable (g) and follow the
steps on screen.
