INSTRUCTION MANUAL
Orion
Congratulations on your purchase of the Orion 80mm ED Binocular Spotting Scope.
This innovative, premium-quality instrument provides comfortable binocular-style
viewing for high-power visual pursuits during both daytime and nighttime. This
spotting scope incorporates the Premium Linear BinoViewer—which is also sold
as an accessory for use with other telescopes—on a 360-degree swivel collar.
Just pop it on a sturdy tripod or equatorial mount and you'll be ready to start exploring your
surroundings near and far in 3D-like magnificence! Please review these instructions before
using the product for the first time. If you run into any problems, contact Orion Customer
Support at 800-676-1343 or by email at www.OrionTelescopes.com/contactus.
WARNING: Never look directly at the Sun through your
telescope—even for an instant—without a professionally
made solar filter that completely covers the front of
the instrument, or permanent eye damage could result.
Young children should use this telescope only with adult
supervision.
A N E M P L O Y E E - O W N E D C O M P A N Y
Copyright © 2020 Orion Telescopes & Binoculars. All Rights Reserved. No part of this product instruction or any of its contents
may be reproduced, copied, modified or adapted, without the prior written consent of Orion Telescopes & Binoculars.
80mm ED Binocular
®
Spotting Scope
#40910
Corporate Offices: 89 Hangar Way, Watsonville CA 95076 - USA
Toll Free USA & Canada: (800) 447-1001
International: +1(831) 763-7000
Customer Support: support@telescope.com
IN 646 11/19
Advertisement
Table of Contents
Related Manuals for ORION TELESCOPES & BINOCULARS 40910
Summary of Contents for ORION TELESCOPES & BINOCULARS 40910
- Page 1 Orion 80mm ED Binocular ® Spotting Scope #40910 Congratulations on your purchase of the Orion 80mm ED Binocular Spotting Scope. This innovative, premium-quality instrument provides comfortable binocular-style viewing for high-power visual pursuits during both daytime and nighttime. This spotting scope incorporates the Premium Linear BinoViewer—which is also sold as an accessory for use with other telescopes—on a 360-degree swivel collar.
- Page 2 Included Components • 80mm ED Binocular Spotting Scope • 12.5mm Edge-On Eyepieces (x2) • Dovetail bar • Heavy Duty Waterproof Case Refer to Figure 1 below to familiarize yourself with the parts of the spotting scope. 12.5mm (40x) eyepieces Figure 2. Attaching a tripod quick-release plate to the bottom of the scope’s mounting bracket.
- Page 3 Focusing With the two eyepieces installed, cover or close you right eye and look into the left eyepiece with your left eye. Adjust the focus using the telescope’s rubber focusing ring (refer to Figure 1) until you get a sharp image. Now close or cover your left eye and look into the right eyepiece with your right eye.
- Page 4 Telescope spotting scope or eyepieces in order to clean them; this can also void the warranty. Objective Lens: Doublet, includes one element Ohara S-FPL53 extra-low dispersion (“ED”) To clean the telescope’s objective lens and the eyepiece lenses, first glass blow off the lens with a photographer’s blower bulb or gently wipe the lens with a soft lens cleaning brush to remove the larger particles.
