DataMan
470 Series
Quick Reference Guide
2020 April14
Revision: 6.1.6SR1.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 470 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cognex DataMan 470 Series

Summary of Contents for Cognex DataMan 470 Series

  • Page 1 ® DataMan 470 Series Quick Reference Guide 2020 April14 Revision: 6.1.6SR1.7...
  • Page 3 (ESD), power surges, or other irregularities in the power supply. Do not install Cognex products where they are exposed to environmental hazards such as excessive heat, dust, moisture, humidity, impact, vibration, corrosive substances, flammable substances, or static electricity.

  • Page 4: Product Overview

    Ensure that the cable bend radius begins at least six inches from the connector. Cable shielding can be degraded or cables can be damaged or wear out faster if a service loop or bend radius is tighter than 10X the cable diameter.
  • Page 5 Error Peak meter SD card slot Tuning button Ethernet External light control Power, I/O, and RS-232 DataMan 470 Series Accessories LENS OPTIONS AND COVERS DM474 DM475 Accessory 12 mm F8 fixed aperture lens LEC-CFF12-F8 16 mm F8 fixed aperture lens...
  • Page 6 DM474 DM475 Accessory 10 mm F5 autofocus lens* (use with HPIT) DMLN-C10F05-HSLL 10 mm F5 manual focus lens* DMLN-C10F05-MF 16 mm F8 autofocus lens* (use with HPIT) DMLN-C16F08-HSLL 16 mm F8 manual focus lens* DMLN-C16F08-MF 24 mm F6 autofocus lens* (use with HPIT) DMLN-C24F06-HSLL 24 mm F6 manual focus lens* DMLN-C24F06-MF...
  • Page 7 DM474 DM475 Accessory Red LED HPIL, 10.3 mm lens DM360-HPIL-RE (Risk Group Red LED Exempt acc. IEC 62471, Risk Group Green LED Aimer Exempt acc. IEC 62471) Polarized red LED HPIL, ESD safe, 10.3 mm lens DM360-HPIL-RE-P (Risk Group Red LED Exempt acc. IEC 62471, Risk Group Green LED Aimer Exempt acc.
  • Page 8 DM474 DM475 Accessory Dark-field light CLRD-D120G1 Brick light, narrow blue IVSL-ODDM-S75-470 Brick light, narrow red IVSL-ODDM-S75-625 Brick light, narrow white IVSL-ODDM-S75-WHI Bar light, wide red IVSL-YLW2X-625 Bar light, narrow red, linear polarizer IVSL-YLW2X-625P Bar light, narrow infrared IVSL-YLW2X-850 Bar light, narrow blue IVSL-YLW2X-470 Bar light, wide red IVSL-YLW2X-625-W...
  • Page 9 DM474 DM475 Accessory HPIA, Red narrow DM30X-HPIA3-625 HPIA, Red wide DM30X-HPIA3-625-W HPIA, White narrow DM30X-HPIA3-WHI (Risk Group White LED low risk acc. IEC 62471) HPIA,White wide DM30X-HPIA3-WHI-W (Risk Group White LED low risk acc. IEC 62471) HPIA, Blue narrow DM30X-HPIA3-470 (Risk Group White LED low risk acc.
  • Page 10 DM474 DM475 Accessory Field of view expander with mount DMA-XPAND-100 Field of view expander DMA-XPAND-150 Field of view expander DMA-XPAND-250 Field of view expander DMA-XPAND-300 OTHER DM474 DM475 Accessory Connection cable RS-232 CCB-M12xDB9Y-05 CCB-M12x12Fy-xx Connection cable 24V, I/O, RS-232 (y straight/angled, xx specifies length) Connection cable 24V, I/O, RS-232 CCBL-05-01...
  • Page 11 DM474 DM475 Accessory External light cable (xxx specifies length) CCB-M12x4MS-xxx Compatible with CLRR / CLRB / CLRO / CLRS / CLRD illumination External light control cable for DataMan, 5 CCB-M12XFLY-05 meters in length with flying leads Bar light cable (xxx specifies length: 300, IVSL-5PM12-Jxxx 500, 1000, 2000mm) Compatible with IVSL lights, except IVSL-LX280...
  • Page 13 Dimensions Light emitting area Optical axis DataMan 474 with High Power Integrated Light (HPIL)
  • Page 14 DataMan 470 Series with High power Illumination Accessory (HPIA)
  • Page 15 DataMan 470 Series with High Power Integrated Torch (HPIT)

  • Page 16: Field Of View And Reading Distances

    Field of View and Reading Distances Note: Due to tolerances, ranges can vary by +/- 5 % from unit to unit. Distances in mm / 1D min code Distances in mm / 2D min code Device 10 mm HSLL 10 mm HSLL 6 MIL 6 MIL 8 MIL...
  • Page 17 Distances in mm / 1D min code Distances in mm / 2D min code Device 16 mm HSLL 16 mm HSLL 6 MIL 6 MIL 8 MIL 8 MIL 1125 10 MIL 10 MIL DM47x 1462 13 MIL 1006 13 MIL 1687 15 MIL 1160 15 MIL...
  • Page 18 Distances in mm / 1D min code Distances in mm / 2D min code Device 24 mm HSLL 24 mm HSLL 1029 6 MIL 6 MIL 1370 8 MIL 8 MIL 1711 10 MIL 1178 10 MIL DM47x 2223 13 MIL 1530 13 MIL 2564 15 MIL...

  • Page 19: Connecting The Reader

    Connecting the Reader CAUTION: The Ethernet cable shield must be grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector. A digital voltmeter should be used to validate the grounding.

  • Page 20: Installation

    Cognex > DataMan Software vx.x.x > Documentation. Note: Cables are sold separately. If a standard component is missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are "keyed" to fit the connectors on the DataMan system;...

  • Page 21: Connect The Ethernet Cable

    For more information on mounting, see the DataMan 470 Series Reference Manual. Connect the Ethernet Cable CAUTION: The Ethernet cable shield must be grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector.

  • Page 22: Connect The Breakout Cable

    Never connect voltages other than 24VDC. Always observe the polarity shown. 3. Attach the Breakout cable's M12 connector to the DataMan 470 series reader's 24VDC connector. 4. Restore power to the 24VDC power supply and turn it on if necessary.

  • Page 23: Install Software And Documentation And Connect The Reader

    3. Connect the cable to a 24V power supply. To configure a DataMan 470 series reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman.
  • Page 24 DataMan 470 Specifications 373 g with S-mount adapter, without rubber front cover Weight Power Consumption 24VDC ±10%, 1.5A maximum (HPIL* and HPIT**) 24VDC , 250mA maximum (non-HPIL)* 24VDC, 1000mA (HPIA)*** Supplied by LPS or NEC class 2 only. *HPIL denotes one of the DM360-HPIL-xxx-xx or DMLT-HPIL-xxx-xx accessories. **HPIT denotes one of the DMLT-HPIT-xxx-xx accessories.
  • Page 25 2.0 mA @ 24VDC 4.2 mA 10/100/1000 Ethernet Speed Duplex Mode Full duplex or half duplex DataMan 470 Series Imager Specifications Specification DataMan 474 Imager DataMan 475 Imager Image Sensor 1/1.8 inch CMOS 2/3 inch CMOS 7.2 mm x 5.4 mm (H x V); 3.45 µm square Image Sensor 8.8 mm x 6.6 mm (H x V);...
  • Page 26 55 Hz Image Acquisition max. 37 Hz at Full Resolution See DataMan 470 Series Accessories on page 1* Lens Type *Limitations to C-Mount lenses: The length of the thread may not exceed 5.4 mm. For a chosen lens, the distance from the C-mount shoulder to the bottom of the lens may not exceed 5.4mm.
  • Page 27 Regulations/Conformity Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. DataMan 470 readers have Regulatory Model R00062 and meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow.

  • Page 28: For European Community Users

    2014/30/EU Electromagnetic Compatibility Directive and the 2011/65/EU RoHS Directive. For further information, please contact: Cognex Corporation, One Vision Drive, Natick, MA 01760, USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE.
  • Page 29 The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.
  • Page 30 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
  • Page 31 Copyright © 2019 Cognex Corporation. All Rights Reserved.
