DataMan

Reference Manual

2024 December 20

Revision: 25.1.0.14

290 Series

Need help?

Do you have a question about the DataMan 290 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Cognex DataMan 290 Series

Page 1 ® DataMan 290 Series Reference Manual 2024 December 20 Revision: 25.1.0.14...
Page 2 Copyright © 2025. Cognex Corporation. All Rights Reserved. Portions of the hardware and software provided by Cognex may be covered by one or more U.S. and foreign patents, as well as pending U.S. and foreign patents listed on the Cognex web site at: cognex.com/patents.
Page 3 Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: The reader requires a UL or NTRL listed power supply with a 24 V DC output that meets the following rating...
Page 4 Symbols Symbols The following symbols indicate safety precautions and supplemental information: WARNING: This symbol indicates a hazard that could cause death, serious personal injury or electrical shock. CAUTION: This symbol indicates a hazard that could result in property damage. Note: This symbol indicates additional information about a subject. Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.
Page 5 Emulating Serial Functionality Emulating Ethernet Functionality USB-Keyboard (HID) Functionality Using Your DataMan Reader Connect to DataMan WebUI Installing the DataMan Setup Tool Trigger Types External Triggers Industrial Protocols Specifications DataMan 290 Series Reader DataMan 290 Series Reader Image Sensor LED Wavelengths...
Page 6 Table of Contents Acquisition Trigger Input High-Speed Outputs High Speed Output Wiring Ethernet Cable Power and I/O Breakout Cable (CCB-M12x12Fy-xx) Power and I/O Breakout Cable (CCBL-05-01) Power and I/O Breakout Cable (CCB-PWRIO-xx) Cleaning and Maintenance Clean the Housing Clean the Reader Image Sensor Window Clean the Reader Lens Cover Regulations and Conformity 中...
Page 7 Getting Started Getting Started This section provides general information about the DataMan 290 series reader and the accessories and systems. About the DataMan 290 Series The DataMan 290 series readers are high-performance readers that offer: Embedded AI, industry-proven decoding algorithms, and powerful lighting work together to deliver high read rates.
Page 8 The DM290 Quick Reference Guide provides essential information about the DM290 reader. Cognex > DataMan Software v x.x.x > Documentation > English > DM290 Series > DM290 Quick Reference Guide The DataMan Fixed-Mount Readers Reference is a complete online hardware reference for the DataMan fixed- mount ID readers.
Page 9 Getting Started DataMan 290 Series Systems Illustration Product ID Illumination Lens Front Cover Reader-only Accessory Bundle DM290X-16- DM290X-16-LM- Multi-Purpose Integrated 16 mm high-speed liquid Clear, polarized, Light lens diffuse DM290X-03- DM290X-03-LM- Multi-Purpose Integrated 6.2 mm high-speed liquid Clear, polarized, Light...
Page 10 Getting Started Accessories You can purchase the following components separately. For a list of options and accessories, contact your local Cognex sales representative. Lenses Accessory Illustration 6.2 mm lens 16 mm lens Illumination Accessory Illustration Color Maximum Maximum Duty Cycle...
Page 11 Getting Started Cables Note: Cables are sold separately or as part of an accessory bundle. For more information, contact your Cognex sales representative. Accessory Product Number Illustration Ethernet Cable, X-coded M12-8 to RJ-45 CCB-84901-2001-xx (straight, xx specifies length: 2m, 5m,...
Page 12 Setting Up Your DataMan Reader Setting Up Your DataMan Reader Read this section to learn how the reader connects to its standard components and accessories. DataMan 290 Layout The image and table below shows the elements of the reader. Number Description Power I/O Breakout cable connector USB-C slot (with plastic cover)
Page 13 Setting Up Your DataMan Reader Dimensions The following sections list dimensions of the reader. Note: Dimensions are in millimeters and are for reference purposes only. All specifications are for reference purposes only and can change without notice. DataMan 290 with Multi-Purpose Integrated Light and 6.2 mm Lens...
Page 14 Setting Up Your DataMan Reader DataMan 290 with Multi-Purpose Integrated Light and 16 mm Lens...
Page 15 Setting Up Your DataMan Reader DataMan 290 with Mini Light and 6.2 mm Lens...
Page 16 Setting Up Your DataMan Reader DataMan 290 with Mini Light and 16 mm Lens...
Page 17 Setting Up Your DataMan Reader Reading Distance and Field of View This section provides the Field of View (FoV) values for 6.2 mm and 16 mm lenses. DataMan 290 Reader with 6.2 mm Lens The following tables show the Field of View (FoV) widths of the 6.2 mm lens focused to 105 mm at various distances. Working distance in mm Horizontal values in mm Vertical values in mm...
Page 18 Setting Up Your DataMan Reader DataMan 290 Reader with 16 mm Lens The following tables list the Field of View (FoV) widths of the 16 mm lens at various distances: Working distance in mm Horizontal values in mm Vertical values in mm = 150 = 46 = 34...
Page 19 Setting Up Your DataMan Reader Mounting the Reader The reader provides mounting holes for attachment to a mounting surface. CAUTION: You must ground the reader, either by mounting the reader to a fixture that is electrically grounded or by attaching a wire from the mounting fixture on the reader to frame ground or earth ground. If you use a ground wire, attach the wire to one of the four mounting points on the back plate of the reader and not to the mounting points on the front of the reader.
Page 20 Setting Up Your DataMan Reader Connection Options This section summarizes connection options. For more information on how to connect your DataMan reader to your network, see the DataMan Communications and Programming Guide. Connecting the Ethernet Cable CAUTION: The Ethernet cable shield must be grounded at the far end.Whatever this cable is plugged into (typically a switch or router) should have a grounded Ethernet connector.
Page 21 Setting Up Your DataMan Reader Cable Bend Radius Observe the minimum bend radius for the Ethernet and power cables shown on the following image: Using your DataMan 290 reader through USB You can use the USB connector of the reader in the following ways: Emulating serial (USB-COM) functionality The reader establishes the connection through emulated serial port.
Page 22 Setting Up Your DataMan Reader Note: Do not power the reader exclusively over USB. Any load to the system might cause it to reboot. Emulating Serial Functionality If you connect a USB-C cable, you can see a COM port in the Windows Device Manager as a generic USB-COM port. The client application must have DTR (Data Terminal Ready) enabled.
Page 23 Setting Up Your DataMan Reader USB-Keyboard (HID) Functionality To use the DataMan 290 as an emulated keyboard, set the language of the keyboard in the software. HID reports use the keyboard language set in the drop down menu. You can configure HID functionality with both UI options available for the DataMan 290: To enable the HID interface with the DataMan WebUI, switch the toggle on the Communications substep: To enable HID reports with the DataMan Setup Tool, tick the checkbox on the Communications application step: Note:...
Page 24 MAC address: found on the label of the reader, followed by .local. For example, 00D0243BF53C.local. Host name: the default host name is DM290 and the first six characters of the MAC address, followed by .local. For example, DM290-00D024.local. Station Manager 1. Go to support.cognex.com/downloads/dataman/software-firmware and follow the on-screen steps. 2. Find and select your reader.
Page 25 Follow the steps below to install and connect your reader to the DataMan Setup Tool. 1. Check the DataMan Release Notes for a full list of system requirements. 2. Download the latest version of the DataMan Setup Tool from support.cognex.com/downloads/dataman/software- firmware and follow the on-screen steps.
Page 26 Using Your DataMan Reader Single (external trigger): Acquires a single image and attempts to decode any symbol it contains, or more than one symbol in cases where multicode is enabled. The reader relies on an external trigger source. Presentation: Scans, decodes and reports a single code in the field of view. The reader relies on an internal timing mechanism to acquire images.
Page 27 Scan the appropriate Reader Configuration codes. For more information, see Reader Configuration Codes available through the Windows Start menu, the DataMan Setup Tool Help menu, or DataMan documentation available on the Cognex support site. Send the appropriate DMCC command. For more information, see Command Reference available through the Windows Start menu or the DataMan Setup Tool Help menu.
Page 28 Specifications Specifications The following sections list general specifications for the reader. DataMan 290 Series Reader Specification DataMan 290 Weight DataMan 290 with: Multi-Purpose Integrated Light 6.2 mm Model: 214 g Multi-Purpose Integrated Light 16 mm Model: 234 g Mini Light 6.2 mm Model: 169 g...
Page 29 Specifications DataMan 290 Series Reader Image Sensor Specification Values Image Sensor 1/3-inch CMOS, global shutter Image Sensor Properties Diagonal size: 6.21 mm Pixel size: 3.45 μm (H) Image Resolution (pixels) 1440 × 1080 (1.6 mp) Electronic Shutter Speed Minimum exposure: 43 μs...
Page 30 Specifications Acquisition Trigger Input The reader features one acquisition trigger input, which is optically isolated. You can configure the acquisition trigger input to trigger from an NPN (current sinking) or PNP (current sourcing) device. To trigger from an NPN type photoelectric sensor or PLC output, connect COMMON IN to +24 V DC and connect IN 0 to the output of the photoelectric sensor.
Page 31 Specifications Number Output NPN OUT COMMON OUT For PNP lines, connect the external load between the output and the negative supply voltage (0 V DC). When connected to a 24 V DC power supply, the output pulls up greater than 21 V DC when ON, and current flows through the load. When the output is OFF, no current flows through the load.
Page 32 Specifications To connect to a PNP-compatible PLC input, connect one of the high-speed outputs of the reader directly to the PLC input. When enabled, the output pulls the PLC input up to greater than 21 V DC. To connect the high-speed outputs to a relay, LED or similar load, connect the negative side of the load to the output and the positive side to +24 V DC.
Page 33 Specifications Ethernet Cable The Ethernet cable provides Ethernet connectivity to the reader. The Ethernet cable is used to connect the reader to other network devices. P1 Pin Number Wire Color Signal Name P2 Pin Number White/Orange TxRx A + Orange TxRx A - White/Green TxRx B +...
Page 34 Specifications Power and I/O Breakout Cable (CCB-M12x12Fy-xx) The Power and I/O Breakout cable provides access to trigger and high-speed outputs. For RS-232, use the Power Supply return path for ground. The figure on the left shows the plug on the device. Pin# Signal Names Wire Color...
Page 35 Specifications Power and I/O Breakout Cable (CCBL-05-01) The Power and I/O Breakout cable provides access to trigger and high-speed outputs. For RS-232, use the Power Supply return path for ground. The figure on the left shows the plug on the device. Pin# Signal Names Wire Color...
Page 36 Specifications Power and I/O Breakout Cable (CCB-PWRIO-xx) The Power and I/O Breakout cable provides access to trigger and high-speed outputs. For RS-232, use the Power Supply return path for ground. The figure on the left shows the plug on the device. Pin# Signal Names Wire Color...
Page 37 Cleaning and Maintenance Cleaning and Maintenance Clean the Housing To clean the outside of the reader housing, use a small amount of mild detergent cleaner or isopropyl alcohol on a cleaning cloth. Do not pour the cleaner on the reader housing. CAUTION: Do not attempt to clean any DataMan product with harsh or corrosive solvents, including lye, methyl ethyl ketone (MEK) or gasoline.
Page 38 Regulations and Conformity Regulations and Conformity Note: For the most current CE and UKCA declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Safety and Regulatory Cognex Corporation Manufacturer One Vision Drive Natick, MA 01760 USA DataMan 290: Regulatory Model 50141 This is a class A product.
Page 39 表示用于本部件的至少一种均质材料中所含的危害物质超过GB / T26572 - 2011 的限制要求。 For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).

This manual is also suitable for:

Dataman dm290x-16-lm Dataman dm290x-03-lm Dataman dm290x-16-sp Dataman dm290x-06-sc
