DataMan
475 Verifier
Quick Reference Guide
2022 August 04
Revision: 6.3.2.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 475 Verifier and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cognex DataMan 475 Verifier

Summary of Contents for Cognex DataMan 475 Verifier

  • Page 1 ® DataMan 475 Verifier Quick Reference Guide 2022 August 04 Revision: 6.3.2.5...
  • Page 2 (ESD), power surges, or other irregularities in the power supply. Do not install Cognex products where they are exposed to environmental hazards such as excessive heat, dust, moisture, humidity, impact, vibration, corrosive substances, flammable substances, or static electricity.
  • Page 3 Ensure that the cable bend radius begins at least six inches from the connector. Cable shielding can be degraded or cables can be damaged or wear out faster if a service loop or bend radius is tighter than 10X the cable diameter.
  • Page 4 Symbols The following symbols indicate safety precautions and supplemental information: WARNING: This symbol indicates a hazard that could cause death, serious personal injury or electrical shock. CAUTION: This symbol indicates a hazard that could result in property damage. Note: This symbol indicates additional information about a subject. Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.

  • Page 5: Product Overview

    Product Overview Number Item Lens Label Light attachment Mounting holes (M3 x 5mm) Indicator light ring Ethernet connection External lighting connection (disabled for verification) Breakout cable connection...
  • Page 6 DM475V for Standards Based Grading only. Note: The product images below serve illustration purposes only. You can purchase the following components separately. For a list of options and accessories, contact your local Cognex sales representative. Accessory Product Accessory Accessory Name...
  • Page 7 Accessory Product Accessory Accessory Name Number Illustration Connection module (1 camera) DMA-CCM-1-xx xx can be US, EU, UK or JP Mounting Bracket Kit DMBK-470-MNT Pivot Mounting Bracket DM100-PIVOTM-00 DMHS-370-470 External heat sink DMV-475V-LBL-0200 45° LabelLight...
  • Page 8 Dimensions DataMan 475 Verifier...
  • Page 9 2. Connect the Ethernet cable to a computer or a network switch. 3. Connect the breakout cable to a 24 V power supply. For information on the cable pinout and wire colors, see section Connections, Optics, and Lighting in the DataMan 475 Verifier Reference Manual. Note: Cables are sold separately.
  • Page 10 CAUTION: All cable connectors are "keyed" to fit the connectors on the DataMan system; do not force the connectors or damage may occur. CAUTION: Make sure that the verifier is grounded, either by mounting the verifier to a fixture that is electrically grounded or by attaching a wire from the verifier’s mounting fixture to frame ground or Earth ground.

  • Page 11: Connect The Ethernet Cable

    Connect the Ethernet Cable CAUTION: Make sure that the Ethernet cable is grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector. Use a digital voltmeter to validate the grounding.
  • Page 12 1. Connect the Ethernet cable's M12 connector to the DataMan system's ENET connector. 2. Connect the Ethernet cable's RJ-45 connector to a switch/router or PC, as applicable.

  • Page 13: Connect The Breakout Cable

    Never connect voltages other than 24 VDC. Always observe the polarity shown. 3. Attach the Breakout cable's M12 connector to the DataMan 475 Verifier's 24 VDC connector. 4. Restore power to the 24 VDC power supply and turn it on if necessary.

  • Page 14: Installation

    All cable connectors are "keyed" to fit the connectors on the DataMan system; do not force the connectors or damage may occur. 1. After installing the software, connect the DataMan 475 Verifier to your PC. 2. Launch the DataMan Setup Tool and click Refresh.
  • Page 15 Practical acquisition rate is application dependent. Lens Type 12 mm fixed focal length, f/4 fixed aperture, 2/3 inch sensor format, C-mount lens (users cannot alter or replace it). DataMan 475 Verifier and DPM Specifications Specification DataMan 475 Verifier DataMan 475V DPM...
  • Page 16 Specification DataMan 475 Verifier DataMan 475V DPM 5 mil symbols: +/- 1.5 mm Depth of Field +/- 3 mm 15 mil symbols: +/- 2.5 mm (Working Distance tolerance) Weight 945 g 1002.7 g Field of View 80 x 60 mm...
  • Page 17 Specification DataMan 475 Verifier DataMan 475V DPM Operating 0 °C – 40°C (32 °F – 104°F) Temperature Storage -20°C – 80°C (-4°F – 176°F) Temperature Humidity < 95% non-condensing Environmental IP65 IP65 with cables and appropriate characteristics lens cover attached.
  • Page 18 Specification DataMan 475 Verifier DataMan 475V DPM 1D: 20 codes/second* Maximum 2D: 10 codes/second* 2D: 10 codes/second* Codes per Second Maximum 3.6 ft/second (1.1 m/second) 4.6 ft/second (1.4 m/second) Linear Line Speed Coplanarity +/- 3o of coplanar +/- 2o of coplanar...
  • Page 19 Specification DataMan 475 Verifier DataMan 475V DPM Discrete I/O HS Output 0,1,2,3 @ 12 VDC 50 mA operating 200 Ω limits Input 0 (Trigger) ±15 — ± 28 V Input 1,2,3 0 — ± 5 V @ 12 VDC 2.0 mA @ 24 VDC 4.2 mA...
  • Page 20 LED Wavelengths The following table shows LED types and the related peak wavelengths: λ [nm]...
  • Page 21 Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. DataMan 475 Verifier has Regulatory Model R00062, Label Light (DMV-475V-LBL- 0200) has Accessory Model 50162, and meet or exceed the requirements of all applicable standards organizations for safe operation.

  • Page 22: For European Community Users

    2014/30/EU Electromagnetic Compatibility Directive and the 2011/65/EU RoHS Directive. For further information, please contact: Cognex Corporation, One Vision Drive, Natick, MA 01760, USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE.
  • Page 23 The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.
  • Page 24 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
  • Page 25 Copyright © 2021 Cognex Corporation. All Rights Reserved.
