(ESD), power surges, or other irregularities in the power supply. Do not install Cognex products where they are exposed to environmental hazards such as excessive heat, dust, moisture, humidity, impact, vibration, corrosive substances, flammable substances, or static electricity.
Ensure that the cable bend radius begins at least six inches from the connector. Cable shielding can be degraded or cables can be damaged or wear out faster if a service loop or bend radius is tighter than 10X the cable diameter.
Page 4
DataMan 475 Accessories Accessory CCB-PWRIO-xx Power and I/O breakout cable, M12-12, straight, xx specifies CCB-PWRIO-xxR length: 5 m, 10 m, 15 m, angled, xx specifies length: 5 m, 10 m, 15 m X-Coded to A-Coded Ethernet cable adapter, 0.5 m...
Page 6
2. Connect the Ethernet cable to a computer or a network switch. 3. Connect the breakout cable to a 24 V power supply. For information on the cable pinout and wire colors, see section Connections, Optics, and Lighting in the DataMan 475 Verifier Reference Manual. Note: Cables are sold separately.
Page 7
CAUTION: All cable connectors are "keyed" to fit the connectors on the DataMan system; do not force the connectors or damage may occur. CAUTION: It is recommended the verifier be grounded, either by mounting the verifier to a fixture that is electrically grounded or by attaching a wire from the verifier’s mounting fixture to frame ground or Earth ground.
Connect the Ethernet Cable CAUTION: The Ethernet cable shield must be grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector. A digital voltmeter should be used to validate the grounding.
Page 9
1. Connect the Ethernet cable's M12 connector to the DataMan system's ENET connector. 2. Connect the Ethernet cable's RJ-45 connector to a switch/router or PC, as applicable.
Never connect voltages other than 24 VDC. Always observe the polarity shown. 3. Attach the Breakout cable's M12 connector to the DataMan 475 verifier's 24 VDC connector. 4. Restore power to the 24 VDC power supply and turn it on if necessary.
Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software vx.x.x > Documentation. To configure a DataMan 475 verifier, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site.
Page 12
DataMan 475 Verifier Specifications Specification DataMan 475 Verifier Weight 945 g Field of View 80 x 60 mm Dimensions 185 x 185 x 175 mm Power 24 VDC ±10%, 1.5 A maximum (Label Light, 36 W peak power consumption) Consumption Supplied by LPS or NEC class 2 only.
Page 13
@ 12 VDC 2.0 mA @ 24 VDC 4.2 mA Ethernet Speed 10/100/1000 DataMan 475 Verifier Imager Specifications Specification DataMan 475 Imager Image Sensor 2/3 inch CMOS, global shutter Image Sensor 8.8 mm x 6.6 mm (H x V); 3.45 µm square pixels...
Page 14
When using the C-Mount lens cover, lens dimensions including spacer and filters may not exceed 32 x 42 mm (diameter x length). LED Wavelengths The following table shows LED types and the related peak wavelengths: λ [nm]...
Page 15
Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. DataMan 475 verifiers have Regulatory Model and meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow.
UL 61010-1:2012 + R:2015-07, UL 61010-1:2012 + R:2015-07, EN 61010-1:2010. TÜV SÜD AM, IEC/EN 61010-1. CB report available upon request. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).
