Appendix

Site Requirements

•
Uninterrupted Power System (UPS) - minimum rating of 450VA,
with AC Power Stabilizer (Recommended for continuous
plotting)
•
Temperature Range: 15-35 C (59-95 F)
•
Humidity: 20% - 80% (non-condensing)

Technical Specifications

Print Engine

•
Infinity 45 - Single HP type 51645A
•
Infinity 85 - HP long-life ink delivery system
(alternate configuration - two HP 51645A cartridges)

Host Connectivity

•
RS-232 - baud rates to 57600 bps (Infinity 45/85)
•
Direct 10-base T Ethernet interface (Infinity 85)

Paper

•
Paper widths in continuous rolls from 914 mm-1828 mm (36-72
in.)
•
Plot width to 1816 mm (71.5 in.)
•
Paper rolls up to 241 mm (9.5 in.) with an inner core of 76 mm
(3 in.)

Floor Space Requirements

•
685 mm x 2794 mm (27 in. x 110 in.)

Weight

•
122 kg (270 lbs.)

Power Requirements

The Infinity is connectable to any standard electrical source
•
115/230 VAC +/- 10%
•
Single phase, 47-63 Hz
•
1 KVA
