2.
Raise and engage the nipbar arm (1) (Figure 25).
Figure 25. Nipbar Arm Engagement
Key to Figure
1-Nipbar Arm (Shown engaged)
3.
Close the plotter cover.
4.
Make sure the plotter is offline.
5.
Push the Paper Adv button on the plotter control panel to
advance the paper until it touches the take-up roll.
37
