Paper Monitoring Parameter Table
Paper Monitoring Parameter
Monitor Paper Usage
Paper Remaining
Paper Roll Length
Value For Paper Low Warning
Description
Set to Enable if you want to
receive paper monitoring
messages.
Set to Disable if you do not want
to receive paper monitoring
messages.
Messages will be visible on the
plotter control panel and in the
queue manager status window.
This shows the number of
yards/meters of paper remaining
on the roll.
Range - 0 to 500 yards/meters
Default - The paper roll length
After loading the new paper roll,
click on the New Paper Roll
button on this screen, select the
Paper Roll Length parameter,
and enter the length.
Range 0 to 500 yards
Default 200 yards/meters
Set the low warning value in
yards/meters to remind the
operator that the paper supply is
getting low. See the amount of
paper remaining anytime by
selecting the Paper Remaining
parameter and looking at the
interface status screen or the
queue manager.
Note: Paper Roll Length must be
set first.
Range 0-500 yards/meters
Default 20 yards
