Wolke m600 Universal Operator Manual

Technical Drawings

Printhead

12.9 mm
(0.51 inches)
70.7 mm
(2.78 inches)
122.6 mm
(4.83 inches)
Figure 9-1: Printhead Dimensions
9-2 Technical Drawings
15.5 mm
(0.61 inches)
39.6 mm
(1.56
inches)
52.3 mm
(2.06 inches)
194.6 mm
(7.66 inches)
8.7 mm
(0.34 inches)
Rev AB
