BURNER COMPONENTS - MODEL MSR-DC

NO. DESCRIPTION
1 MOTOR 1/8 STANDARD
MOTOR 1/8 LOW AMP
2 MOTOR ADAPTOR
3 BLOWER WHEEL 3 1/2 X 4 1/4
4 BURNER HOUSING
5 IGNITOR-12VDC
6 MOUNTING BASE
7 HOUSING COVER
8 SLOT COVER PLATE
9 INNER AIR BAND
10 OUTER AIR BAND
11 COUPLING
12 OIL LINE ASSEMBLY 6"
OIL LINE ASSEMBLY 8"
13A FUEL UNIT: SUNTEC COMBO
13B FUEL UNIT: SUNTEC
13C FUEL SOLENOID
14 ELBOW (USE WITH 13A)
15 GUN ASSEMBLY
16 AIR TUBE/FLANGE ASM
NOTE: WHEN ORDERING STATE BURNER MODEL MSR, SPEC#, WHAT USABLE AIR TUBE LENGTH, AND FIRING RATE.
12
STATE BURNER MODEL, PART DESCRIPTION AND
PART NUMBER WHEN ORDERING PARTS
NO.
PART NO.
17 AIR CONE - #3A
21993-005
AIR CONE - #4A
21993-006
18 GASKET
100761-001
19 CONNECTOR (USE WITH 13B, 13C) 14222
21427
20 CAD CELL
SEE NOTE
21 CONTROL BOX
31812-003
22 TIMER, DROP OUT
100730-001
23 COVER, CONTROL BOX
21723-002
13392
Suggested Combustion Chamber Dimensions
20601-002
20602-002
Firing
101119-001
Rate
14451
(G.H.P)
14452
0.85
1.00
101128-005
1.25
13495
1.35
100610-005
1.50
1.65
13494
2.00
SEE NOTE
2.50
SEE NOTE
3.00
DESCRIPTION
Conversion or Upgrading
Chamber Dimensions (In Inches)
Square Round
Width Length
8.5 8.5 8.5
9 9 10 1 ⁄
8
10 10 11 1 ⁄
4
10 1 ⁄ 10 1 ⁄ 11 3 ⁄
2 2 4
11 11 12 3 ⁄
8
11 1 ⁄ 11 1 ⁄ 13
2 2
12 5 ⁄ 12 5 ⁄ 14 1 ⁄
8 8 4
14 1 ⁄ 14 1 ⁄ 16
4 4
15 ⁄ 15 ⁄ 17 ⁄
1 1 1
2 2 2
PART NO.
14157
14160
12484
14289
63355-001
100889-002
62899
Height Floor
to
Nozzle
8.5 8.5
12 1 ⁄ 5-6
2
12 1 ⁄ 5-6
2
12 3 ⁄ 5-6
4
13 5-6
13 1 ⁄ 5-6
4
13 1 ⁄ 6-7
2
14 7-8
15 7-8
