- Page 1 Direct Gear Drive Power Sweep Retrofit Wheel Kit Models: 8" AND 10" SD DGD BIN SWEEP (15' - 48') 10" HD DGD BIN SWEEP (30' - 72') Installation Manual PNEG-2314 Version 1.0 Date: 06-26-20 PNEG-2314...
- Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
-
Page 3: Table Of Contents
Retrofit Sweep Wheel Kit Installation for Heavy Duty ..............19 Chapter 4 Parts List ..........................25 Retrofit Sweep Wheel Kit Parts - Standard Duty................25 Retrofit Sweep Wheel Kit Parts - Heavy Duty................26 Limited Warranty — N.A. Grain Products ................27 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... - Page 4 NOTES PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
-
Page 5: Chapter 1 Safety Precautions
Personnel operating or working around equipment must read this manual. This manual must be delivered with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the equipment. ST-0001–4 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... -
Page 6: Cautionary Symbol Definitions
This symbol is used to address practices not related to personal injury. This symbol indicates a general hazard. This symbol indicates a prohibited activity. This symbol indicates a mandatory action. ST-0005–2 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... -
Page 7: Safety Cautions
ST-0002–1 Sharp Edge Hazard • This product has sharp edges, which can cause serious injury. • To avoid injury, handle sharp edges with caution and always use proper protective clothing and equipment. ST-0036–2 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... - Page 8 • Always use sturdy and stable supports when needed for installation. Not following these safety precautions creates the risk of falling equipment, which can crush personnel and cause serious injury or death. ST-0047–1 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 9 • Be aware of pinch points, which can trap or catch objects and cause injury. • Be sure all equipment is locked in position before operating. • Always lock out all power sources to the equipment when unloading is finished. ST-0051–1 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
-
Page 10: Safety Sign-Off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety instructions. This sign-off sheet is provided for your convenience and personal record keeping. Date Employee Name Supervisor Name ST-0007 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... -
Page 11: Chapter 2 Retrofit Sweep Wheel Kit Installation For Standard Duty
Backshield Sweep wheel Torque tube bracket (GK80715) Sweep wheel mount 3/8" x 3/4" flange bolt (S-9067) 1/2" x 3" HHCS bolt (S-8252) 3/8" x 3/4" carriage bolt (S-7391) 1/2" stover lock nut (S-8315) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... - Page 12 3. Using the retrofit template (14) as a reference, mark the four field drill holes (15) and two field cut slots (21) on the backshield (1). Figure 2-3 Marking the field drill holes on the backshield Backshield Field drill holes Retrofit template (GC21309) Field cut slots PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 13 (17) as a reference, mark and field drill two holes (22) in the top and bottom flanges of the backshield (1). Figure 2-5 Field drilling holes for torque tube bracket Field drill holes for torque tube bracket Backshield Torque tube bracket (GK80715) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 14 7. Assemble the retrofit bracket (4) to the backshield (1) using four 3/8" x 1" flange bolts (12) and 3/8" flange nuts (10). Figure 2-7 Installing the retrofit bracket to the backshield 3/8" flange nut (S-968) Backshield 8" retrofit bracket (GC21125) 3/8" x 1" flange bolt (S-9065) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 15 9. Before installing the sweep wheel assembly (16), use a 9/16" drill bit and field drill through the hole (23) in the wheel assembly shaft to fit the 1/2" HHCS bolt. Figure 2-9 Drilling through the hole in the wheel shaft Sweep wheel assembly (TG00203) Wheel shaft hole PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 16 1/2" x 3" HHCS bolt (7) and a 1/2" stover lock nut (8). Figure 2-11 Attaching the sweep wheel assembly to the flight section 8" retrofit bushing (GC21136) Flight section 1/2" x 3" HHCS bolt (S-8252) Sweep wheel assembly (TG00203) 1/2" stover lock nut (S-8315) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 17 13.Attach the deflector plate (5) to the sweep wheel assembly (16) using the supplied 5/16" bolts (11). Figure 2-12 Attaching the deflector plate to the sweep wheel assembly Wheel deflector plate (GC21286) Sweep wheel assembly (TG00203) 5/16" bolt PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 18 NOTES PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
-
Page 19: Chapter 3 Retrofit Sweep Wheel Kit Installation For Heavy Duty
Backshield Sweep wheel 3/8" x 1" flange bolt (S-9065) Sweep wheel mount Backshield reinforcement plate (GK81029) 1/2" x 3" HHCS bolt (S-8252) 3/8" x 3/4" flange bolt (S-9067) 1/2" stover lock nut (S-8315) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... - Page 20 (1) and mark the top two holes (15). Remove the retrofit bracket (4) and field drill the marked holes (15) in the backshield (1). Figure 3-3 Field drill holes for retrofit bracket in the backshield Backshield Field drill holes for retrofit bracket 10" retrofit bracket (GC21124) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 21 5. Before installing the sweep wheel assembly (16), use a 9/16" drill bit and field drill through the hole (23) in the wheel assembly shaft to fit the 1/2" HHCS bolt. Figure 3-5 Drilling through the hole in the wheel shaft Sweep wheel assembly Wheel shaft hole PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 22 1/2" x 3-1/2" HHCS bolt (7) and a 1/2" stover lock nut (8). Figure 3-7 Attaching the sweep wheel assembly to the flight section 10" retrofit bushing (GC21135) Flight section 1/2" x 3-1/2" HHCS bolt (S-8314) Sweep wheel assembly 1/2" stover lock nut (S-8315) PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 23 9. Attach the deflector plate (5) to the sweep wheel assembly (16) using the supplied 5/16" bolts (11). Figure 3-8 Attaching the deflector plate to the sweep wheel assembly Wheel deflector plate (GC21198) Sweep wheel assembly 5/16" bolt PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
- Page 24 NOTES PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation...
-
Page 25: Chapter 4 Parts List
Bolt, Carriage 3/8"-16 x 1" ZN Grade 5 S-3585 Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange S-968 5/16" Bolts Bolt, Flange 3/8"-16 x 1" ZN Grade 5 S-9065 Flight Section Retrofit Template for Springland Wheel - 8" GC21309 PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... -
Page 26: Retrofit Sweep Wheel Kit Parts - Heavy Duty
Nut, Lock 1/2"-13 ZN Grade C S-8315 Bolt, Carriage 3/8"-16 x 1" ZN Grade 5 S-3585 Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange S-968 5/16" Bolts Bolt, Flange 3/8"-16 x 1" ZN Grade 5 S-9065 Flight Section PNEG-2314 DGD Retrofit Sweep Wheel Kit Installation... -
Page 27: Limited Warranty - N.a. Grain Products
12 months from the date of shipment (or, if shipped by vessel, 14 months from the date of arrival at the port of discharge). If, in GSI’s sole judgment, a product is found to have a defect in materials and/or workmanship, GSI will, at its own option and expense, repair or replace the product or refund the purchase price. - Page 28 Authorities having jurisdiction should be consulted before installations are made. 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com Copyright © 2020 by The GSI Group, LLC Printed in the USA CN #359792...
