- Page 1 S2 Quick Start Guide Canister Installation Manual PNEG-1724 Date: 07-21-10 PNEG-1724...
- Page 2 PNEG-1724 S2 Quick Start Guide Canister...
-
Page 3: Table Of Contents
Chapter 1 Safety ..............................4 Safety Guidelines ..........................4 Safety Instructions ..........................5 Operator Qualifications ......................... 9 Chapter 2 General Information ...........................10 Chapter 3 Installation ............................11 Chapter 4 Parts List .............................14 Components ............................14 Chapter 5 Warranty ..............................15 PNEG-1724 S2 Quick Start Guide Canister... -
Page 4: Chapter 1 Safety
CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage. NOTE indicates information about the equipment that you should pay special attention. PNEG-1724 S2 Quick Start Guide Canister... -
Page 5: Safety Instructions
Grain augers can kill or dismember. Keep clear of all augers and never enter the bin unless all power is disconnected and locked out. Failure to do so will result in serious injury or death. Rotating Flight PNEG-1724 S2 Quick Start Guide Canister... - Page 6 Prepare for Emergencies Be prepared if fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance service, hospital and fire department near your telephone. Keep Emergency Equipment Quickly Accessible PNEG-1724 S2 Quick Start Guide Canister...
- Page 7 A respirator may be needed to prevent breathing potentially toxic fumes and dust. Hard Hat Wear hard hat to help protect your head. Wear appropriate fall protection equipment when working at elevations greater than six feet (6'). Fall Protection PNEG-1724 S2 Quick Start Guide Canister...
- Page 8 • ALWAYS lock out ALL power to the equipment when finished unloading a bin. • Be aware of pinch points. A pinch point is a narrow area between two surfaces that is likely to trap or catch objects and so is a potential safety hazard. PNEG-1724 S2 Quick Start Guide Canister...
-
Page 9: Operator Qualifications
All unqualified persons are to stay out of the work area at all times. It is strongly recommended that another qualified person who knows the shut down procedure is in the area in the event of an emergency. Date Employee Name Supervisor Name PNEG-1724 S2 Quick Start Guide Canister... -
Page 10: Chapter 2 General Information
NEVER enter a grain bin unless ALL power driven equipment has been shut down. Disconnect and lock out power before entering the bin or servicing the equipment. ALWAYS keep ALL guards and shields in place, until all the power is disconnected and locked out. PNEG-1724 S2 Quick Start Guide Canister... -
Page 11: Chapter 3 Installation
3. Find a suitable position to mount the canister. GSI recommends that the canister be installed close to the Series II Sweep Operational Control Panel and the bin entry door. The height chosen should allow the canister to be easily recognized and utilized. - Page 12 (2) brackets and fasten together with three (3) 5/16"-18 nylock nuts. (See Figure 3B.) Figure 3B 8. Attach the canister to the canister bracket with three (3) 5/16"-18 x 1-1/4" bolts and nylock nuts. (See Figure 3C.) Figure 3C PNEG-1724 S2 Quick Start Guide Canister...
- Page 13 9. Place one of the quick start guides (PNEG-1723) in the canister and replace the cap. Make sure that the rubber gasket is inserted between the canister body and the canister cap. The other guide should be placed in the work area for reference. (See Figure 3D.) Figure 3D PNEG-1724 S2 Quick Start Guide Canister...
-
Page 14: Chapter 4 Parts List
5/16"-18 x 1-1/4" HH Bin Bolt w/ Washer YDP Grade 5 S-7382 5/16"-18 Nylock Nut Zinc Grade 5 PNEG-1723 Series II Sweep Quick Start Guide Pre-June 2010 PNEG-1759 Series II Sweep Quick Start Guide Post-May 2010 PNEG-1724 Quick Start Guide Installation Manual PNEG-1724 S2 Quick Start Guide Canister... -
Page 15: Chapter 5 Warranty
14 months from arrival at port of discharge, whichever is earlier. The end-user’s sole remedy (and GSI’s only obligation) is to repair or replace, at GSI’s option and expense, products that in GSI’s judgment, contain a material defect in materials or workmanship. - Page 16 Authorities having jurisdiction should be consulted before installations are made. GSI Group 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com Copyright © 2010 by GSI Group Printed in the USA...
