Maya Coffee Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
9
12
Attach panel [9] into panel [12] and secure 4 x bolts (A) and 4x locking
nuts (B) into holes in the panels and tighten with screwdriver.
mocka.co.nz | mocka.com.au
9
9
10
9
Slide panel [13] between the grooves on panels [9] and [4] to form the
back of the unit as shown.
4
6
