Maya Coffee Table

Assembly Instructions

Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
A
C
x4
6
Attach panel [5] into panel [6] and secure 4 x bolts (A) and 4 x dowel (C).
Slot together with the rest of the structure as shown. Place 4x locking
nuts (B) into holes in the panels and tighten with screwdriver.
mocka.co.nz | mocka.com.au
B
x4
6
5
2
A
x6
7
Attach panel [2] into panel [7] and secure 6 x bolts (A) and 4 x dowel (C).
Slot together with the rest of the structure as shown. Place 6x locking
nuts (B) into holes in the panels and tighten with screwdriver.
B
x6
2
7
