10 Specifications
Supply Voltage
Dimensions
Operating Temperature Range
Storage Temperature Range
Mass*
Dry Heat Test
Damp Heat Test
Cold Test
Supply Fuse Rating
UK/EU Approvals
Electromagnetic Compatibility: VCA Type Approval Number: xxx*xx/xxx*xxxx/xx*xxxx*xx
Measuring Instruments Directive (MID) (2004/22/EC): CE xxxxxx & xxxxxx
*
Not including Looms, Secure tariff cover and fixing straps.
12V DC Nominal (9V - 16V)
281 x 81 x 35mm
-10C to +85C
-40C to +85C
310g Approx.
Tested in accordance with IEC Publication 68-2-2 test B
Tested in accordance with IEC Publication 68-2-30 test D
Tested in accordance with IEC Publication 68-2-1 test A
10A
57
CYGNUS
