Cooper Security Scantronic 770r Quick Start Manual

Repeater mode
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
770r
Repeater Mode
Quick Start Guide

Advertisement

Table of Contents
loading

Related Manuals for Cooper Security Scantronic 770r

Summary of Contents for Cooper Security Scantronic 770r

  • Page 1 770r Repeater Mode Quick Start Guide...

  • Page 2: Table Of Contents

    Contents Introduction ..................3   Before You Begin ................. 4   1. Carry Out a Radio Site Survey ............4   2. Prepare the WAM: ................4   3. Set the WAM to the Mode 1 (Repeater) ..........4   Teach the Control Unit the Identity of the Detectors ......

  • Page 3: Introduction

    Introduction In mode 1 the WAM acts as a repeater for some Cooper radio and hybrid alarm systems. The WAM receives signals from transmitters that are out of range of the radio expander. The WAM repeats these signals and, because the WAM is nearer the expander, the expander can now hear the signals and respond to them.

  • Page 4: Before You Begin

    Before You Begin 1. Carry Out a Radio Site Survey Cooper Security strongly recommend that you carry out a radio site survey to find the best position for the WAM. You must choose a position for the WAM so that a) the nearest radio...
  • Page 5 a) Press SELECT repeatedly until LED 7 glows. b) Press SET. The blue LEDs show the current mode. When delivered from the factory the WAM is in mode 1 (LED 1 glowing). 4. If necessary, select mode 1 by pressing SELECT repeatedly until LED 1 lights up.

  • Page 6: Teach The Control Unit The Identity Of The Detectors

    Teach the Control Unit the Identity of the Detectors To Teach Detectors To An i-on40 1. Enter Installer Menu. INSTALLER MENU Detectors/Devices > 2. Press Y. DETECTORS/DEVICES Detectors > 3. Press Y . DETECTORS/DEVICES The display shows: Add/Del Detectors > 4.
  • Page 7 2. Press SELECT. DETECTORS The displays shows: Add/Del Detectors Edit Zones Select Back 3. Press SELECT. ADD/DEL DETECTORS Auto learn The display shows: Delete All Zone 01 Zone 02 Select Back 5. Press SELECT. The display shows: Activate detector tamper Back 6.

  • Page 8: Teach The Control Unit The Identity Of The Wam

    Teach the Control Unit the Identity of the WAM To Teach an i-on40 At The i-on40: 1. Enter Installer Menu. INSTALLER MENU Detectors/Devices > 2. Press Y. DETECTORS/DEVICES Detectors > 3. Press n until the display shows: DETECTORS/DEVICES WAMs > 4.

  • Page 9: To Teach A 7510R

    1. Press Y ADD/DEL WAM The display shows that the control unit is *WAM 02 > now ready to select another WAM. To check that the control unit has learned the correct mode for the WAM: 2. Press X. WAMS Add/Del WAM >...
  • Page 10 3. Press SELECT. OTHER DEVICES External Siren The displays shows: Info Module Arming Station Select Back 4. Press n until the display shows: OTHER DEVICES External Siren Info Module Arming Station Select Back 5. Press SELECT. WAMs The display shows: Add/Del WAM View WAM Select...

  • Page 11: On The Wam

    ZONES OUTPUTS WAM No. WAM Zone Panel Zone WAM No. WAM OP No. Panel OP 1 (HW) 2 (HW) Table 1. WAM Zones and OPs to Panel Zone and OPs On the WAM 1. Apply power to the WAM. 2. Make sure the tamper switch operates. You can do this by either opening the WAM lid (if it is currently closed) OR by leaving programming and closing the...

  • Page 12: At The 7510R

    At the 7510r When the control unit learns the WAM’s Add/Del WAM WAM 1 identity the control unit gives a double WAM 2 beep. The display shows that the WAM 3 memory slot you selected is now WAM 4 Select Back occupied, for example: To check that the 7510r has learned the correct mode for the WAM:...

  • Page 13: Teach The Wam The Identity Of The Detectors

    Teach the WAM the Identity of the Detectors Adding Devices 1. Enter programming mode as follows: a) Open the tamper switch. The Red Trouble LED glows. b). Press SELECT. The blue LED 1 glows. The WAM is in menu 2. Press SET. If any blue LEDs flash then those channels are already in use.

  • Page 14: Deleting Devices

    Deleting Devices If you need to delete detectors from a WAM, perhaps in order to move them from one repeater to another, then: 1. Enter programming mode as follows: a) Open the tamper switch. The Red Trouble LED glows. b). Press SELECT. The blue LED 1 glows.
  • Page 15 b) Close the lid tamper. After a few seconds the WAM bleeps twice and the red Trouble LED goes dark. NOTE: You must leave programming mode in order to save the changes you have made. Page 15...
  • Page 16 Every effort has been made to ensure that the contents of this book are correct. However, neither the authors nor Cooper Security Limited accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this book. The contents of this book are subject to change without notice.
