Dynacode

Compact Flash Card

Select layout
Keys:
Load file from Compact Flash card
Keys: ,
Key:
Save layout onto Compact Flash card
Keys: , ,
Key:
Save configuration
Keys: , , ,
Change directory
Keys: , , ,
Key:
118
Press keys and to select the desired label in STANDARD directory.
Press key to select the layout.
Select the number of layouts which you want to print.
Press key to start the print order.
Select the file you want to load and then confirm your selection with
Press key and enter the desired number you want to print. Confirm the selection with
and the print order is started by an external signal (Input 1, PIN 1 and PIN 4).
Select the directory and layout you want to save and then confirm your selection with
Confirm the above query with
As standard, the proposed file name is config.cfg. This name can be changed by the user. In
this file the parameters of print module are saved which are not saved permanent in the
internal Flash.
Press key to start the saving procedure.
,
The lower line of display shows the directory which is selected at the moment.
Press keys and to change the directory in the upper line.
Press keys and to show all available directories.
Press key to confirm the selected directory.
and the layout is saved.
