USER GUIDE
ELECTRIC STRETCHER SERIE PC-750 //
STRETCHER SUPPORT SERIE PB-720
Review 01/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC-750 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Promeba PC-750 Series

Summary of Contents for Promeba PC-750 Series

  • Page 1 USER GUIDE ELECTRIC STRETCHER SERIE PC-750 // STRETCHER SUPPORT SERIE PB-720 Review 01/16...
  • Page 3 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INDEX INTRODUCTION 01.1 Using this manual 01.2 Technical data sheet INSTALLATION 02.1 Transport and unpacking 02.2 Anchorage points 02.3 Connection to the mains power supply 02.4 Stretcher’s launch OPERATION 03.1 Commands of the support PB-720 03.2 Commands of the support PB-725...
  • Page 4 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INDEX 04.23 Bill of platform ensamble PB-720 04.24 Exploded views of ensamble platform PB-720 04.25 Bill of platform ensamble PB-725 04.26 Exploded views of platform ensamble PB-725 04.27 Bill of supplement ensamble PB-720 04.28 Exploded views of supplement ensamble PB-720 04.29...
  • Page 5 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INTRODUCTION 01.1 Using of manual The manual provides using and maintenance instruc- tions of the product, as well as the way of fixing minor faults that could appear. It is recommended before the operation of the product to read carefully this manual in order to avoid damages caused by a misuse.
  • Page 6 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INTRODUCTION 01.2 Technical data sheet MEASUREMENTS AND FEATURES // PC-750 STANDARD STRETCHER LENGHT 2000 mm POWER SUPPLY 12 V. CC. WIDTH 590 mm USING UP POWER HEIGHT MIN/MAX 420-1300 mm TRENDELEMBURG 30º...
  • Page 7 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INTRODUCTION MEASUREMENTS AND FEATURES // PC-755 INCUBATOR STRETCHER LENGHT 2000 mm POWER SUPPLY 12 V. CC. WIDHT 575 mm USING UP POWER HEIGHT MIN/MAX 390-1270 mm OPERATOR REQUIRED WEIGHT 65 Kg LOAD HEIGHT 920 mm MAX.
  • Page 8 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INTRODUCTION MEASUREMENTS AND FEATURES // PB-720 SUPPORT WITH CABINET LENGHT 2000 mm POWER SUPPLY 12 V. CC. WIDHT 590 mm USING UP POWER HEIGHT MIN/MAX. 420-1300 mm TRENDELEMBURG 30º FOWLER 17º...
  • Page 9 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INTRODUCTION MEASUREMENTS AND FEATURES// PB-725 SUPPORT WITHOUT CAB. LENGHT 2000 mm POWER SUPPLY 12 V. CC. WIDHT 575 mm USING UP POWER HEIGHT MIN/MAX 390-1270 mm OPERATOR REQUIRED WEIGHT 80 Kg LOAD HIGHT 920 mm MAX.

  • Page 10: Installation

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INSTALLATION 02.1 Transport and unpacking First carefully remove the packaging to prevent the da- mage of the product. Take the wooden cover away and use a crane to move vertically. 1.

  • Page 11: Anchorage Points

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INSTALLATION 02.2 Anchorage points Before putting the stretcher support into operation, ensure that each and every anchorage points are pla- ced and clasped. ANCHORE FOR PB-720 · PB-725 (8 anchorage points) LIMIT AMBULANCE FLOOR 441mm MÁXIM USE SCREWS DIN-7991 - M12 - 10.9...
  • Page 12 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 INSTALLATION 02.3 Connection to the mains power supply PB-720 / PB-725 To make the connection follow the steps below. Be particularly careful when the connecting the stretcher support to the required voltage of 12V and do not leave cables in passageways and or moving elements.
  • Page 13 Straightaway charge to the maximum the two batteries with their PROMEBA’s charger supplied. (APPROXIMATELY 30 MIN. ARE ENOUGH) Charge only the batteries of the stretcher with the charger supplied by PROMEBA, otherwise the batteries could be damaged and lose their guarantee.

  • Page 14: Operation

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.1 Commands of the SUPPORT PB-720 Removable handle to pull the support Anchor point to lock the stretcher Accomodation cabinet for scoop stretcher Loading point for stretcher Central hooks for stretcher Removable lateral lever for folding the stretcher support Removable bearing for stretcher support Pull handle the rail from inside the ambulance...
  • Page 15 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.2 Commands of the SUPPORT PB-725 Removable handle to pull the support Anchor point to lock the stretcher Loading point for stretcher Central hooks for stretcher Removable push botton to fold the support stretcher Removable bearing for stretcher support Pull handle the rail from inside the ambulance Guides for engagement operation...
  • Page 16 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.3 Commands of the STRETCHER PC-750 Foldable and reclining handrails Retractable belts on the backrest Touch control panel in the middle Batteries cabinet with lock Four lockable wheels Telescopic frame for maneuvering Bed with fowler and trendelemburg Folding and adjustable IV pole Powerful LED lighting on the sides...
  • Page 17 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.4 Commands of the INCUBATOR STRETCHER PC-755 Stainless steel tray for incubator Touch control panel in the middle Batteries cabinet with lock Four lockable wheels Telescopic frame for maneuvering Powerful LED lighting on the sides Emergency switch Automatic integrated charging system...
  • Page 18 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.5 Elements of the manual system SUPPORT PB-720 / PB-725 LATERAL DISPLACEMENT Hand lever Operate the lever located on the rear of the right side of the support, making a slight effort with foot and ac- companing that movement by sliding with hands.
  • Page 19 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.6 Elements of the manual system STRETCHER PC-750 / PC-755 Foldable and reclining handrails Adjust the backrest inclination Adjust maximum high of the stretcher Stretch the lateral knob to fold the handrail or Have 6 positions.

  • Page 20: Loading And Unloading Operation

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.7 Loading and unloading operation THE FRONT WHEELS OF THE STRETCHER MUST BE LOCKED WHEN THE LOADING/ UNLOADING OPERATION ARE EXECUTED. Starting from the position in which the support has been left after the loading of the stretcher into the ambulance (1): ON THE CONTRARY, IT IS POSSIBLE IM- PORTANT ELEMENTS OF THE STRETCHER...

  • Page 21: Control Panel

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.8 Control panel CONTROL PANEL FUNCTION All the electrical functions of the stretcher are controlled from the touch control panel placed on the back of the stretcher. See its functions in the following graphic: LED ROJO (FALLO BATERÍAS) LED ROJO...
  • Page 22 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 OPERATION 03.9 Breakdowns HYDRAULIC SYSTEM FAILURE In case of hydraulic system failure, the stretcher has a lever that allows to fold it on manual mode. For that, locate the lever on left side of battery case: Pull the lever and the stretcher will descend until its lower position.
  • Page 23 - VOLTAGE BATTERY IS LESS THAN 34V - OVERCHARGE DURING THE CHARGING - COOL THE BATTERIES DURING 3/4 HOURS BATTERIES OV - USE THE CHARGER SUPPLIED BY PROMEBA - REPLACE BATTERIES FOR NEW ONES - THE STRETCHER IS NOT RECEIVE VOLTA- - FAIL CONNECTION STRETCHER-SU-...
  • Page 24 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.1 Main exploded of STRETCHER PC-750 / PC-755 PC-755 TOP SET SEE PAGE 30 DETAIL PC-750 TOP SET SEE PAGE 30 DETAIL PC-750 LOWER ENSAMBLE SEE PAGE 30 DETAIL...
  • Page 25 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.2 Main exploded of SUPPORT PB-720 / PB-725 PB-720 / PB-725 TOP SET SEE PAGE 30 DETAIL PB-720 LOWER ENSAMBLE SEE PAGE 30 DETAIL PB-725 LOWER ENSAMBLE SEE PAGE 30 DETAIL...
  • Page 26 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.3 Bill of materials: LOWER ENSAMBLE PC-750 / PC-755 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-03002 - SUBCONJUNT BASE RODES ESQUERRA PC7500-06002 - SUBCONJUNT POTA EXTERIOR DRETA PC7500-05002 - SUBCONJUNT POTA EXTERIOR ESQUERRA PC7500-01160 - CONJUNT RODA GIRATORIA AMB FRE PC7500-04002 - SUBCONJUNT BASE RODES DRET...
  • Page 27 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.4 Exploded views of lower ensamble PC-750 / PC-755...

  • Page 28: Bill Of Materials

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.5 Bill of materials: UPPER ENSAMBLE PC-750 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-11002 - CONJUNT GUIES SUPERIORS PC7500-13012 - GUIA PASSACABLES GRUP ACTUADOR PC7500-12000 - CONJUNT COMPARTIMENT BATERIES PC7500-10000 - CONJUNT MARC CAPÇAL EXTENSIBLE PC7500-15000 - CONJUNT BARANETA ABATIBLE ESQUERRA PC7500-16000 - CONJUNT BARANETA ABATIBLE DRETA...
  • Page 29 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS Nº ELEMENT CODE - DESCRIPTION QUANTITY 3111308251 - TORNILLO ISO7380 M8X25 CINCADO 31201061 - ARANDELA D-125 M6 CINCADA 3111306501 - TORNILLO ISO7380 M6X50 CINCADO 051329 - ARANDELA D-9021 M4 CINCADA 31305041 - TUERCA D-985 M-4 CINCADA 3111304301 - TORNILLO ISO7380 M4X30 CINCADO 3110808301 - TORNILLO D-7991 M8X30 CINCADO...
  • Page 31 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.6 Exploded views of upper ensamble PC-750...
  • Page 32 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.7 Bill of materials: UPPER ENSAMBLE PC-755 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-11002 - CONJUNT GUIES SUPERIORS PC7500-12000 - CONJUNT COMPARTIMENT BATERIES PC7500-10000 - CONJUNT MARC CAPÇAL EXTENSIBLE PC7500-09000 - CONJUNT CUADRE DE MANDOS PC7500-14002 - SUBCONJUNT SUPORT CAPÇAL DE CARREGA PC7500-17000 - CONJUNT CAPÇAL DE CARREGA CAMILLA...
  • Page 33 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.8 Exploaded views of upper ensamble PC-755...
  • Page 34 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.9 Bill of materials: CONTROL PANEL SET PC-750 / PC-755 Nº ELEMENT CODE - DESCRIPTION QUANTITY 3110805163 - TORNILLO D-7991 M5X16 PAVONADO 212412-3 - TORNILLO DIN-7983 M5X32MM PAVONADO 3140105TP15 TUERCA REMACHABLE M-5 CON VALONA TP-15 PC7500-09012 - SUBCONJUNT TUB QUADRE DE MANDOS PC7500-09070 - FUNDA TUB QUADRE DE MANDOS...
  • Page 35 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.10 Exploaded views CONTROL PANEL SET PC-750 / PC-755...
  • Page 36 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.11 Bill of materials: FRAME SET PC-750 / PC-755 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-10010 - Perfil telescopic capçal extensible PC7500-10020 - Cantonera suport roda marc capçal esquerra PC7500-10030 - Cantonera suport roda marc capçal dreta PC7500-10040 - Tub unió...
  • Page 37 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 SET UP AND QUARTERING 04.12 Exploading FRAME SET PC-750 / PC-755...
  • Page 38 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.13 Bill of materials: BATTERIES CABINET SET PC-750 / PC-755 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-12012 - SUBCONJUNT CAIXA COMPARTIMENT BATERIES PC7500-12062 - SAFATA ANCLATGE BATERIES PC7500-12072 - SAFATA PLACA ELECTRICA 1056-U30 - BISAGRA ARMARI EMKA REF.
  • Page 39 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.14 Exploaded views of BATTERIES CABINET SET PC-750 / PC-755...
  • Page 40 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.15 Bill of materials: LEFT HANDRAIL ENSAMBLE PC-750 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC6501-04040 - SUPORT ACCIONAMENT PC6501-04170 - CASQUELL SEPARADOR L30 PC6501-04112 - TUB OVAL BARANETA PC6501-04160 - GATELL I MANETA ACCIOMANENT BARANETA PC6501-04140 - MOLLA GATELL BARANETA PC6501-04100 - SUPORT ARRASTRE...
  • Page 41 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.16 Exploaded views of LEFT HANDRAIL ENSAMBLE PC-750...
  • Page 42 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.17 Bill of materials: RIGHT HANDRAIL ENSAMBLE PC-750 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC6501-04040 - SUPORT ACCIONAMENT PC6501-04112 - TUB OVAL BARANETA PC6501-04160 - GATELL I MANETA ACCIOMANENT BARANETA PC6501-04140 - MOLLA GATELL BARANETA PC6501-04100 - SUPORT ARRASTRE PC6501-04090 - CASQUELL SEPARADOR L25...
  • Page 43 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.18 Exploaded views RIGHT HANDRAIL ENSAMBLE PC-750...
  • Page 44 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.17 Bill of materials: HEADREST SET OF STRETCHER’S LOADING PC-750 / PC-7559 Nº ELEMENT CODE- DESCRIPTION QUANTITY PC7500-17010 - CARCASSA CAPÇAL DE CARREGA CAMILLA PC7500-17020 - BORN COURE CAPÇAL CARREGA CAMILLA 31204051 - ARANDELA D-9021 M5 CINCADA 3110205151 - TORNILLO D-912 M5X15 PC6500-01340 - MOLLA BLOQUEJADOR POTA...
  • Page 45 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.20 Exploaded views of HEADREST SET OF STRETCHER’S LOADING PC-750 / PC-755...
  • Page 46 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.21 Bill of materials: STRETCHER’S BED SET PC-750 Nº ELEMENT CODE - DESCRIPTION QUANTITY PC7500-18052 - SUBCONJUNT TUB RESPATLLER PC6500-06230 - CONJUNT REGULADOR RESPATLLER PC6500-06312 - SUBCONJUNT XAPA FIXE LLITERA PC6500-06011 - SUBCONJUNT SOPORT GIR LLITERA TAP-PLASTØ20 - TAPON PLASTICO FINAL Ø20 - MOD.
  • Page 47 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.22 Exploaded views of STRETCHER’S BED SET PC-750...
  • Page 48 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.23 Bill of materials: PLATFORM ENSAMBLE PB-720 Nº ELEMENTO CODIGO - DESCRIPCIÓN CANTIDAD PB4200-01162 - SUBCONJUNT TENSOR TOPE PB4200-01122 - SUBCONJUNT PALANCA PEU PB4100-02360 - GOMA PEDAL MOVIMENT LATERAL PA5100-05031 - MOLLA ESPIRAL 3060 - RODA POSTERIOR 60MM PB4200-01210 - GUIA MOVIMENT LATERAL...
  • Page 49 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.24 Exploaded views of PLATFORM ENSAMBLE PB-720...
  • Page 50 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.25 Bill of materials: PLATFORM ENSAMBLE PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB4200-01122 - SUBCONJUNT PALANCA PEU PB4100-02360 - GOMA PEDAL MOVIMENT LATERAL 3060 - RODA POSTERIOR 60MM PB4200-01210 - GUIA MOVIMENT LATERAL PB4100-01000 - CONJUNT PLETINA COLLADA PB4020-00110 - CASQUELL AMB VALONA Ø12-17X12...
  • Page 51 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.26 Exploaded views of PLATFORM ENSAMBLE PB-725...
  • Page 52 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.27 Bill of materials: SUPPLEMENT ENSAMBLE PB-720 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB4100-04420 - BRIDA SUBJECCIO PALES PB4200-02112 - XAPA TOPE CAMILLA PB4200-02090 - CASQUELL SOPORT CAMILLA PB4200-02082 - U TOPE PALAS 496379 - PASACABLES MOSS IP67 M20 PB4100-00291 - VALDA FIXACIO...
  • Page 53 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.28 Exploaded views of SUPPLEMENT ENSAMBLE PB-720...
  • Page 54 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.29 Bill of materials: FIXED SUPPORT STRETCHER SYSTEM PB-720 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-03000 - CONJUNT PLATAFORMA PB-720 PB7200-04000 - CONJUNT SUPLEMENT PB-720 PB7200-10000 - CONJUNT CAPÇAL DE CARREGA PB-720 PB7200-11000 - CONJUNT TENCA TERCER PUNT PB-720 PC6500-05100 - CINTA SUBJECCIÓ...
  • Page 55 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.30 Exploaded views of FIXED SUPPORT STRETCHER SYSTEM PB-720...
  • Page 56 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.31 Bill of materials: FIXED SUPPORT STRETCHER SYSTEM PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-10000 - CONJUNT CAPÇAL DE CARREGA PB-720 PB7200-11000 - CONJUNT TENCA TERCER PUNT PB-720 PB7200-02010 - SAFATA INOX RAIL PB-720 PB7200-02022 - GANXO CENTRAL RAIL PB7200-02030 - PERFIL EXTERIOR GUIA RAIL...
  • Page 57 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.32 Exploaded views of FIXED SUPPORT STRETCHER SYSTEM PB-725...
  • Page 58 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.33 Bill of materials: REMOVABLE SUPPORT STRETCHER SYSTEM PB-720/PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-12002 - SUBCONJUNT RAIL EXTRAIBLE PB-720 PB7200-13002 - SUBCONJUNT VARILLA DESBLOQUEIG RAIL EXTRAIBLE PB7200-14012 - SUBCONJUNT SUPORT RODA RAIL EXTRAIBLE PB7200-01022 - SUPORT RODA RAIL EXTRAIBLE PB7200-01010 - PERFIL UNIO RAIL EXTRAIBLE A GUIES...
  • Page 59 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-01220 - TOPE EXTRACCIÓ RAIL EXTRAIBLE 3110206301 - TORNILLO D-912 M-6X30 CINCADO 3110205151 - TORNILLO D-912 M5X10 CINCADO 31201051 - ARANDELA D-125 M5 CINCADA 3111305161 - TORNILLO ISO7380 M5X16 CINCADO 3111308301 - TORNILLO ISO7380 M8X30 CINCADO 31203063 - ARANDELA D-6798A PARA M6 PAVONADA...
  • Page 60 MONTAJE Y DESPIECE...
  • Page 61 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.34 Exploaded views of REMOVABLE SUPPORT STRETCHER SYSTEM PB-720/PB-725...
  • Page 62 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.35 Bill of materials: SET PLATE PB-720/PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB4100-01012A - SUBCONJUNT PLETINA COLLADA PB4100-00462 - ANGLE SOPORT CABLE PER TENSOR PB4010-00040 - TENSOR UNIVERSAL 31301071 - TUERCA D-934 M-7 CINCADA PC6170-03291 - BRIDA SUBJECCIÓ...
  • Page 63 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.36 Exploaded views of SET PLATE PB-720/PB-725...
  • Page 64 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.37 Bill of materials: ANCHOR POINT SET PB-720/PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-11012 - SUBCONJUNT TENCA TERCER PUNT PB4400-03130 - MOLLA GANXOS PB4550-02221 - SUPORT MOLLA AVELLANAT PA5500-00021 - SUPORT MOLLA 31204101 - ARANDELA D-9021 M10 CINC 3110410201 - TORNILLO D-933 M10X20 CINCADO...
  • Page 65 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.38 Exploaded views of ANCHOR POINT SET PB-720/PB-725...
  • Page 66 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.39 Bill of materials: LOADING HEAD SET PB-720/PB-725 Nº ELEMENT CODE - DESCRIPTION QUANTITY PB7200-10010 - CARCASSA CAPÇAL DE CARREGA RAIL PB7200-10020 - BORN COURE CAPÇAL CARREGA RAIL 3110805161 - TORNILLO D-7991 M5X16 CINCADO 31201051 ARANDELA D-125 M5 CINCADA 3110205201 - TORNILLO D-912 M5X20...
  • Page 67 USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 MOUNTING AND COMPONENTS 04.40 Exploaded views of LOADING HEAD SET PB-720/PB-725...

  • Page 68: Electrical Circuit Diagram

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 ELECTRICAL CIRCUIT DIAGRAM 05.1 Plate circuit board Diagram Battery connection 2 Buzzer signal Ambulance battery 12v CC Battery connection 1 Strip lights signal LED right Strip lights signal LED left Hose connection CARD - DRIVER (V1) Supply DRIVER (Positive/Negative) Microwitches signal (load/down/up)

  • Page 69: Electrical Wiring Diagram

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 WIRING DIAGRAM 05.2 Electrical wiring diagram Wiring lines Power input line (12v CC) Microswitch line load terminal Final microswitch line of superior run Electro-hydraulic group connection line (24v CC) Final micro-switch line of lower run Supply line left LED lights Supply line right LED lights Communication line of control panel...

  • Page 71: General Maintenance

    USER GUIDE // STRETCHER PC-750 + SUPPORT PB-720 Review 01/16 GENERAL MAINTENANCE CLEANING WEAR AREAS Keeping the equipment cleaned is essential to ensu- Regularly examining the system’s components to re a good use and durability of the set. It is necessary check if they are wearing out is a preventive measure to make a periodical thorough cleaning, especially in that can reduce breakdowns.

  • Page 72: Legal Notices

    Changes are periodically added to the information he- rein; these changes will be incorporated in new eddi- tions of the publication. Promeba, S.L. reserves the right to make any modifica- tion or improvement in the products described in this publication if it is appropriate.

  • Page 73: Product Warranty

    Promeba, S.L. is not liable for loss or damages to pro- c) Damages or defects resulting from the use, operation ducts, this warranty or others, including economic loss or improper treatment of the product and not caused by or not assessable damage;...
  • Page 74 Todos los derechos reservados. Reservado el derecho ha modificaciones sin previo aviso. Promeba, S.L. no se considera responsabe de los daños causados por la falta o la inexactitud de la información aquí mencionada. All rights reserved. Variations can be done whitout notice.
