- Page 1 Adaptec AUA-2000/3100LP/ 4000A/5100 USB2connect Adapter Installation Guide...
- Page 2 Introduction This Guide describes how to install Adaptec AUA-2000, AUA-3100LP, AUA-4000A and AUA-5100 adapters in Windows computers. These USB (Universal Serial Bus) adapters are compatible with USB 1.1 and USB 2.0 devices and work in virtually any PCI slot. Note: Refer to the Readme file on the CD for operating system support.
- Page 3 The AUA-4000A and AUA-5100 adapters are shown below. AUA-4000A Note: The AUA-5100 has an internal USB connector (in addition to five external connectors). For details on enabling the internal connector, refer to the USB2connect User’s Guide on the CD. External...
-
Page 4: Kit Contents
Kit Contents If you purchased your USB2connect adapter from a retail distributor, your kit contains the following items: One Adaptec USB2connect adapter Printed USB2connect Installation Guide USB2connect CD containing: USB2connect User’s Guide in Acrobat Reader format Acrobat Reader software Drivers... - Page 5 Installing the USB2connect Adapter Discharge any static electricity from your body by touching a grounded metal object (such as the exposed metal parts on the back of your computer) before handling the USB2connect adapter. Turn off power to the computer and disconnect the power cord. Open the computer cabinet.
- Page 6 Low-profile computers only– To install the AUA-3100LP adapter in a low-profile computer, replace the existing full-height bracket with the low-profile bracket included in your kit. Remove and replace the bracket attachment screws on the adapter as shown below.
- Page 7 Insert the USB2connect adapter in the PCI expansion slot. Press the adapter firmly into the slot until it clicks into place. Replace the slot cover screw. When installed properly, the adapter should be level with the expansion slot, as shown below. Close the computer cabinet and reattach the power cord.
- Page 8 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 USA © 2002 Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. Part Number: 513288-06, Ver. AA LB 07/02...
