ERNG-X
dopsm2107x012
Section 6: Drawings
6.1
ERNG-X Dimensions
8.3
[210.8]
3.0
[76.2]
1.9
[47.2]
(ADAPTOR FITTING INCLUDED
TO ADAPT TO MALE 1/8" NPT)
6.0
[152.4]
0.9
[22.6]
All dimensions are reference & nominal
Metric [millimeter] equivalents are in brackets
Section 6: Drawings
4.9
[123.4]
1/2" SAE
5.7
[144.1]
2X 1/2" – 14 NPTF
1.1
[27.5]
2.4
[61.0]
LEFT SIDE VIEW
Figure 4. ERNG-X Dimensions
15.75
[400.0]
14.75
[374.6]
FRONT VIEW
11.2
2.5
[283.3]
[64.0]
3X 1/4" – 18 NPT
BOTTOM VIEW
BREAK OUT SECTION
1.1
[28.6]
RIGHT SIDE VIEW
Section 6: Drawings
January 2017
2X 1/4" – 18 NPT
4X Ø9.92 mm
5.0
[127.0]
2X 1/4" – 18 NPT
1.0
[26.1]
1.0
[26.1]
1/4" – 18 NPT
1/8" – 27 NPTF
0.9
[23.5]
